i-tec MySafe USB-C M.2 SSD External Case
SPECIFICATION
• External USB-C case for M.2 B-Key SATA Based
SSD discs
• Transferrable interface: 1x USB-C 3.1, Gen. 2 (up
to 10Gbps)
• Compatible with M.2 B-Key SATA Based SSD discs
with sizes 2230, 2242, 2260, 2280
• Plug & Play function
• Active LED diode indicating the case state (lights –
is connected, twinkles – record/reading is going
on)
• Power supply 5V, 900mA
• Weight: 44 g
• Dimensions: 110 x 40 x 9 mm
SYSTEM REQUIREMENTS
Windows 7/8/8.1/10 32/64bit, macOS 10.x and higher –
automatic installation of drivers from the system. A free
USB-C port.
M.2 DISC HARDWARE INSTALLATION
Go on according to the following instructions:
1. Screw out 2 pcs of screws on the connector side of
the case and take off the cover.
2. Take out the motherboard.
3. Insert M.2 disc so that the slot in the disc
corresponds to the slot on the M.2 connector. After
that, screw up the M.2 disc on the opposite side to
the motherboard. Insert the motherboard together
with the M.2 disc back and screw up the pair of
the screws.
4. Connect a USB cable to the case. Now the device is
ready for using.
SOFTWARE INSTALLATION
Windows 7/8/8.1/10 32/64bit or macOS 10.x and higher
After connecting the device to a computer, detection
6 |
ENGLISH
and automatic installation of drivers from the system
will be performed.
Remark: The case surface can be warmed up during
operation. It is a usual operational feature and doesn't
mean a defect. This warming-up is caused by cooling
the electronics inside the case. We recommend not
covering the case by things.
Remark: To ensure correct function of the device, firstly
it is necessary to format the disc. Proceed according
to the below mentioned instructions. As far as the disc
was earlier used, it may not be a necessity. By disc
formatting, you will always lose already saved data. We
recommend that you save important or valuable data in
more than one discs or other data recording media
FORMATTING A NEW HDD
1. Click with the right button on „Desktop".
2. Select „Administrate".
3. Click on „Disc administration".
4. Select HDD with the marking „Unassigned" or
„Uninitialized" and with the specified capacity of
the inserted disc (usually a number lower by same
digit places is displayed).
5. Provided the disc is not initialized, click on the left
field by the right button and select „Initialize disc".
6. Click with the right button on the area of the disc
and select „New simple bunch", click on „Next".
7. Leave the maximum bunch size and click on „Next".
8. Select „Assign a letter of the unit" and click on
„Next".
9. Select „Format the bunch with the following
setting" (leave the initial settings). Click on „Next"
and „Finish".
10.
HDD will be formatted. The duration of
formatting depends on the HDD size; afterwards
the HDD will be viewable in the system.
PACKAGE CONTENT
• External case for M.2 disc
• USB-C cable (45 cm)
Quick Start
| 7
ENGLISH
