TECHNICAL DATA

Minimum dynamic pressure:______________________________________________________________0.5 bar
Maximum operational pressure:_____________________________________________________________5 bar
Recommended operational pressure:______________________________________________________1-5 bar
It's recommended to use a pressure reducer in case of
static pressure superior than 5 bar inside the waterpipe.
Maximum hot water temperature:___________________________________________________________80°C
Two spray function:_____________________________________________________________________rain, mist
Chromotherapy:________________________________________________________________________led (RGB)
Connection G1/2" F for rain
G1/2" F hose connection for nebulizer
Flow rate:______________________________________________________________________11 lt/min at 3 BAR
Input voltage:_________________________________________________________________________100 - 240 V
Output voltage:___________________________________________________________________________12V 3A
Operating temperature:_________________________________________________________________-10 40 °C
Battery remote control:_______________________________________________________________CR2025 3V
INSTALLATION, MAINTENANCE AND PRELIMINARY CHECKING PROCEDURE
In order to get your device work correctly and fi ne in time, must ensure compliance with the
mode of installation and maintenance described in this booklet. Relying on a qualifi ed plumber.
Make sure that the system is free from all debris and impurities existing.

CEILING INSTALLATION

Fig. 1: Drill the ceiling to install the carter.
Drill hole size: 285 mm x 185 mm - 11.22 in x 7.28 in.
Ceiling cavity at least: 100 mm - 3.93 in
Fig. 2: Arrange 4 holes (Ø10) into the ceiling with a centre to centre distance of 160 mm - 6.29 in,
using the given template.
Fig. 3: Insert the rawplug inside the hole, tighten the nut until is completely locked.
Fig. 4: Place fi xing carter next to the ceiling and fasten it with the nuts.
Fig. 5: Cut the threaded bar in excess close to the nut.
Fig. 6: Connect the flexy hoses (G1/2" F) for water supply. Connect the cable to the control unit.
After connecting the body to the system, turn on the stopcocks and check that the mixer tap unit
operates correctly. Keep the tap pressurised for a few minutes checking eventual leaks.
Fig. 7: Fix the shower head to the frame with 4 screws
CLEANING
In order to get a correct cleaning, exclusiveny wash with soap and water, rewash and dry with
deerskin and a soft cloth. Avoid to use alcohol, solvents, solid or liquid detergents made by
corrosive or acid substances, towel made by synthetic materials, abrasive sponges, because they
could irreversibly alterate the treated surfaces.
