OVERVIEW
1. Tuning knob
2. USB port
3. Standby indicator
4. Standby button
5. Function button
6. Previous button
7. Next button
8. Play/Pause button
9. Stop button
10. REC button
OPERATION
Listen to FM radio
•
Press standby button [4] and the default mode is FM radio mode.
•
Turn the tuning knob [1] to search for the FM radio station manually.
•
Press the button [8] to search stations and save stations with name P01, P02, etc.
•
Press buttons [6], [7] to switch between saved stations.
•
Plug in the USB drive to the USB port [2] at the front of the unit; press the REC button [10], the REC indicator [12] will
light up and the radio program will be recorded into USB drive; press the REC button [10] again to save the recorded
file and stop recording.
Playing a CD
•
Press the function button [5] to enter into the CD mode; press OPEN/CLOSE button [13] to open the disc tray, place
disc label side up on the tray, press OPEN/CLOSE button [13] to close the tray; press the PLAY/PAUSE button [7], the
disc will start playing once loaded.
•
To pause playback press the PLAY/PAUSE button [8], to continue playback press PLAY/PAUSE button [8] again.
•
To stop playback press STOP button [9].
•
To skip backwards through tracks, press PREV button [6] . To skip forwards through tracks press NEXT button [7].
•
Press the REC button [10], the REC indicator [12] will light up and the CD will be recorded into USB drive; press the
REC button [10] again to save the recorded file and stop recording.
Playing from USB drive
•
Press the function button [5] to enter into the USB mode; it will play automatically when the USB drive is plugged in.
•
To pause playback press the PLAY/PAUSE button [8], to continue playback press PLAY/PAUSE button [8] again.
•
To stop playback press STOP button [9].
•
To skip backwards through tracks, press PREVIOUS button [6]. To skip forwards through tracks press NEXT button [7].
Playing a vinyl record
•
Before playing a record please unlatch the Tone Arm Lock [26] and remove the cartridge protector from the
cartridge/needle.
•
Press the function button [5] to enter into the PHONO mode; place the record on the turntable [22], select the speed
required using the Speed Selector [23], then gently place the needle on the record, the turntable will start spinning
when AUTO STOP switch is ON position.
•
Besides the Speed selector, there is an AUTO STOP ON/OFF Switch [25] besides the Speed selector [23]. If the
AUTO STOP ON/OFF Switch is turned ON, the record will stop automatically when finished(For some few vinyl
records, it will stop when it does not come to the end or it will not stop when it comes to the end). If Auto Stop Control is
turned OFF, record will NOT stop automatically when finished.
•
Press the REC button [10], the REC indicator [12] will light up and the vinyl records will be recorded into USB drive;
press the REC button [10] again to save the recorded file and stop recording.
Listen to an external source
•
To listen to an external source, such as an MP3 player or smartphone, connect a suitable cable (3.5mm jack to 3.5mm
jack) to the AUX IN socket [17] at the back of this unit, and press the function button [5] to enter into the AUX in mode.
•
Press the REC button [10], the REC indicator [12] will light up and the external source will be recorded into USB drive;
press the REC button again to save the recorded file and stop recording.
Playing via BT
•
Press the function button [5] to enter into the BT mode.
•
The BT indicator [11] will become blue colour with flashing.
•
Turn on your BT function on your mobile phone or tablet PC and then search the record player with its name RP135.
After pairing and connection, the BT indicator [11] will become blue colour without flashing, and you can play your
music of your mobile phone or tablet PC on this record player.
•
Press the REC button [10], the REC indicator [12]will light up and the BT wireless music will be recorded into USB
drive; press the REC button again to save the recorded file and stop recording.
Enjoy music via headphone
Connect your headphone to the headphone socket [16] to enjoy music via headphone.
Remark: at the modes CD, USB, Phono, AUX IN,BT, this record player will automatically enter into standby status if the
playback is not going on for approx.15 minutes. You need to press the standby button [4] to let it work.
11. BT indicator
12. Record indicator
13. Open/Close button
14. Volume control knob
15. Antenna
16. Headphone port
17. AUX Input
18. RCA output
19. Power ON/OFF
20. DC Input
4
21. 45RPM Adaptor
22. Turntable platter
23. Speed selector
24. Tonearm
25. Autostop Switch ON/OFF
26. Tone Arm Lock
27. Cartridge/needle
