Verify the Package Contents

Verify that all the components below have been provided. If any item is missing or damaged, please contact your dealer
immediately. Do not install a damaged or incomplete appliance. Make sure that you have everything necessary to ensure
proper installation before proceeding.
Use and care manual
Mounting screws (Wood, #6 X ¾, Dacor PN 83331,
4 for single ovens, 6 for double ovens)
Standard oven racks (single ovens come with 1,
double ovens come with 2)
GlideRack™ oven rack (single ovens come with 2,
double ovens come with 4)

Remove the oven door(s)

Remove the door(s) to reduce weight and make the
oven easier to lift.
WARNING
• Do not attempt to disengage the hinge catches with
the door removed from the oven. The hinge springs
could release, causing personal injury.
• Do not lift or carry the oven door by the door handle.
• On double ovens, remove the bottom door first to
reduce the chance of damage.
1. Open the door to its fully opened position.
2. Using a pair of needle nose pliers and a flat blade
screwdriver, rotate the catch over the retaining arm on
each hinge.
3. Lift the oven door to about a 15° angle from the vertical
position.
4. Hold the door with both hands just below the handle
and pull it away from the oven while continuing to lift.
8

Installation Instructions

Broil grill and pan
Dacor Stainless Steel Cleaner
(stainless steel models only)
Meat probe
Gripping
point
Catch
Retaining
arm
Steps 1 and 2
Gripping
point
Steps 3 and 4
