(STEP 1 cont .)
Mount outside antenna. L-bracket
mount and hardware is provided to
mount to ladder or pole . If installing
with spring, the side exit adapter
must be used . Then route 7.6 meters
RG-6 cable from inside RV to outside
antenna .
NOTE: Outside antenna location must
be within reach of the booster with
the 7 . 6 meters coax cable . The system
performs best with maximum vertical
and horizontal separation .
L-Bracket Mount
& hardware
Side Exit
Adapter
add thread
locker
Spring
(optional)
add thread
ladder rail
locker
