9.9 Terminal Box
The terminal box is designed to provide IP66 (NEMA-4) protection to the terminal block, voir
paragraphe 6.2
Installation électrique
surface mounted using the flanges and holes provided. It should be mounted in such a manner to allow
the free flow of air around the unit. Ambient temperatures should be kept within the range of 0 to 50°C.
Technical data for the power supply:
AC input
DC output
Operating temperature
Humidity
58
en page 25, and a power supply for the sensor. The box should be
100 – 240 VAC 50/60 Hz
24 VDC / 1.1 A
-20 to 60°C
20 to 90%, non-condensing
Figure 42: Terminal Box (RAYMAPB)
Rev. D8 Sep 2017
