Parts

Refrigerator
GB
17
19
16
15
1
5
6
8
16
1 2 3 4
RC600
2 3 4
11
10
RC200
5
6
7
8
9 17
10
11
19
16
12
15
13
14
23
1. Main switch (optional)
2. Front panel
3. Lock
4. Controller
5. Fan panel
6. Fan
7. Shelf support
8. Shelf
9. Clip
10. Gasket
11. Door
4
1 2 3 4
RC400
20 18
12. Small shelf
13. Door down hinge
14. Down panel
15. Door support
16. Plug
17. Evaporator
18. Water container
19. Discharge outlet
20. Compressor
21. Condenser fan
22. Condensator
23. Handle
