13
part
by screws
pass connector
refer to step 3. (Please hold upper
door by hand when installing)
① Special flange screws
② Upper hinge
MODEL WITHOUT DISPLAY
① Special flange screws
Upper hinge
Electrical connector
MODEL WITH DISPLAY
16.
Connect electrical connector
as shown in the picture, then fix part
by screw
refer to step 2.
.Before fix part
through hinge
,
electrical connector
upper hinge cover
self tapping screw
-
MODEL WITH DISPLAY
17. Open the upper door, mount door
racks and then close it.
Note:
If your appliance has handle,you
have to reverse handle by follow
instructions below.
Remove the upper door and place it
on a smooth surface with its panel
upwards. Lever part
then loose screws
the picture. Change handle
right side, then install screws
part
and part
and part
, as shown in
to the
,
in turn.
① Handle covers
② Special screws
③ Handle
④ Screw hole cover
,
