9. Place the lower door on a smooth
surface with its panel upwards.
Loose screw ③ and take down part
② and part ① , Install replacement
door stopper-left
plastic bag) and part
to the left side with screw
part ① with the appliance for future
reference.
10. Change screw hole covers on
middle cover plate from left to right
(as shown in figure below).
11. Tip the refrigerator backwards,
remove part ②.
④ provided (in the
② (stop block)
③ . Keep
①
②
③
④
⑤
① Lower hinge part (right)
② Adjustable bottom feet part
③ Adjustable bottom feet part
④ Self-tapping screws
⑤ Adjustable bottom feet part
12. Remove part ③
hinge pin, loose out the lower hinge
pin, change it to the reverse hole
site, and then tighten into position,
then install part ③
hinge pin.
13. Replace the items remount in
step 11, change part
then fix them with screws
part ② at last.
Lower hinge part (left)
14. Slot the lower door onto the
bottom hinge pin and hold in
position. Turn the middle hinge by
180°, change the washer on the axis
to the lower side, adjust the middle
hinge to the appropriate position and
then install it ensuring the lower
door in secured place.
Note: washer may
stick to lower door.
15. Move the upper door to an
appropriate position, and then fix
12
from the lower
on the lower
① to left and ,
④. Install
Washer
