ASSEMBLY INSTRUCTIONS
Step 2
Wall Hanging installation
NOTE: TWO OR MORE
PERSONS MUST WORK
TOGETHER TO INSTALL
THE UNIT ONTO THE
WALL.
Step 1
Extra Shelf installation
M4 x 38 mm Wood Screw
KK
M4 x 14 mm Wood Screw
MM
x 8
Wall Anchor
RR
SS L Bracket
x 4
Always use a quality level to ensure the shelf is level
while installing.
x 8
x 8
O
If holes coincide with wooden studs, it is recommended
you use the screws in those holes.
