Page 1
ITEM #0339203, 0339204, 0339205, 0339206, 0810374, 2416433 allen + roth is a registered trademark ® COMPLETE CLOSET KIT of LF, LLC. All Rights Reserved. MODEL #WSWS-CS1C, WSWS-CS1W WSWS-CS1P, WSWS-CS1S, WSWS-CS1G, LWCKBW Français p. 22 ATTACH YOUR RECEIPT HERE Español p. 43 Serial Number...
Page 2
TABLE OF CONTENTS PACKAGE CONTENTS Camlock System Operation....................2 Package Contents....................... 3 Hardware Contents.......................4 Safety Information....................... 6 Preparation ......................... 6 Assembly Instructions......................7 Care and Maintenance ....................... 17 Troubleshooting........................17 Warranty..........................19 Replacement Parts List ...................... 19 CAM LOCK SYSTEM OPERATION DETAIL A DETAIL B CAM LOCK...
Page 3
HARDWARE CONTENTS (shown not actual size) HARDWARE CONTENTS (shown not actual size) 1/4 x 1-1/4 in. Lock Flat Large Medium Large Drawer Handle L - Bracket Barrel Nut Bolt Washer Washer Cam Lock Cam Bolt Cam Bolt Qty. 1 Qty. 8 Qty.
Page 4
ASSEMBLY INSTRUCTIONS SAFETY INFORMATION Base Assembly Please read and understand this entire manual before attempting to assemble, operate or install 1. Press the release lever on slides (U) and the product. remove the slide runner. • Do not allow children to climb or play in or around this product. Release Lever •...
Page 5
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS 4. Attach base panel right (I) to assembly using large 7. Attach base panel left (H) to assembly using large wood dowels (HH) and large cam locks (DD). wood dowels (HH) and large cam locks (DD). Note: Make sure previously inserted medium cam bolts Note: Make sure previously inserted medium cam bolts (EE) are completely seated.
Page 6
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS 10. Attach hutch panel left (A) and hutch panel right (B) to 12. Carefully rest hutch assembly on its side. Insert hutch panel back (D) and either front curved stretcher (E) barrel nuts (VV) and large cam bolts (UU) into the or front straight stretcher (F) -- depending on which fits bottom of the hutch assembly.
Page 7
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS 15. Insert drawer bottom panel (T) into drawer left 18. Insert the drawer into the assembly by pressing Hutch panel (R), drawer right panel (Q) and drawer back down the release levers on the slide runners and panel (S).
Page 8
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Long Shelf Installation Wall Hanging Installation Note: If long shelf (V) needs cut to fit inside your closet 21. Using a stud finder, locate the edges of the wood 16 in. space, cut only one side of the shelf and do not use studs.
Page 9
ASSEMBLY INSTRUCTIONS CARE AND MAINTENANCE Pole Installation • Periodically check to make certain all components are properly positioned, free from damage and firmly connected. 25. Insert 22 mm metal poles (X) into 25 mm metal • Use a soft, clean cloth that will not scratch the surface when dusting. poles (Y).
Page 10
Reinstall the wall hanging cleats and PART DESCRIPTION PART # level. ensure they are level. Hutch Panel Left *WSWS-CS1C/W/P/S/G/LWCKBW-1-HPL Hutch Panel Right *WSWS-CS1C/W/P/S/G/LWCKBW-2-HPR Hutch Panel Top *WSWS-CS1C/W/P/S/G/LWCKBW-3-HPT Closet tower can not The mounting hole locations are Reinstall wall hanging cleats; make...
Page 11
*WSWS-CS1C/W/P/S/G/LWCKBW-46-M4AW Touch-up Pen *WSWS-CS1C/P/S/G-50-TUP Open Pole Holder *WSWS-CS1C/W/P/S/G/LWCKBW-48-OPH Closed Pole Holder *WSWS-CS1C/W/P/S/G/LWCKBW-49-CPH M4 x 15 mm Self-tapping Screw *WSWS-CS1C/W/P/S/G/LWCKBW-47-15SS Complete Hardware *WSWS-CS1C/W/P/S/G/LWCKBW-48-CH Printed in Vietnam allen + roth® is a registered trademark of LF, LLC. All Rights Reserved. Lowes.com/allenandroth Lowes.com/allenandroth...
Page 12
• sophisticated • inspiring ARTICLE #0339203, 0339204, 0339205, 0339206, 0810374, 2416433 allen + roth® est une marque de commerce ENSEMBLE COMPLET POUR déposée de LF, LLC. Tous droits réservés. LE PLACARD MODÈLE #WSWS-CS1C, WSWS-CS1W WSWS-CS1P, WSWS-CS1S, WSWS-CS1G, LWCKBW JOIGNEZ VOTRE REÇU ICI Numéro de série...
Page 13
TABLE DES MATIÈRES CONTENU DE L’EMBALLAGE Fonctionnement du système Camloc ................23 Contenu de l’emballage..................... 24 Quincaillerie incluse......................25 Consignes de sécurité....................... 27 Préparation ........................27 Instructions pour l’assemblage..................28 Entretien ........................... 38 Dépannage........................38 Garantie..........................40 Liste des pièces de rechange.................... 40 FONCTIONNEMENT DU SYSTÈME CAMLOC DÉTAIL A DÉTAIL B...
Page 14
QUINCAILLERIE INCLUSE (non illustrée à la grandeur réelle) QUINCAILLERIE INCLUSE (non illustrée à la grandeur réelle) Écrou à portée Boulon de 1/4 Rondelle de Rondelle Grande attache Vis Camloc Grande vis Poignée de tiroir Support en L cylindrique po x 1 1/4 po blocage plate Camloc...
Page 15
INSTRUCTIONS POUR L’ASSEMBLAGE CONSIGNES DE SÉCURITÉ Assemblage de la base Assurez-vous de lire et de comprendre l’intégralité du présent manuel avant de tenter 1. Appuyez sur le levier de dégagement sur les d’assembler, d’utiliser ou d’installer le produit. Levier de glissières (U) et retirez la pièce coulissante.
Page 16
INSTRUCTIONS POUR L’ASSEMBLAGE INSTRUCTIONS POUR L’ASSEMBLAGE 4. Fixez le panneau droit de la base (I) à l’ensemble 7. Fixez le panneau gauche de la base (H) à l’ensemble à l’aide de goujons de bois longs (HH) et de grandes à l’aide de goujons de bois longs (HH) et de grandes attaches Camloc (DD).
Page 17
INSTRUCTIONS POUR L’ASSEMBLAGE INSTRUCTIONS POUR L’ASSEMBLAGE 10. Fixez le panneau gauche de l’étagère (A) et le panneau droit de l’étagère (B) au panneau arrière (D), ainsi que 12. Déposez soigneusement l’ensemble de l’étagère l’entretoise avant courbée ou droite (selon le style de sur le côté.
Page 18
INSTRUCTIONS POUR L’ASSEMBLAGE INSTRUCTIONS POUR L’ASSEMBLAGE 15. Insérez le fond du tiroir (T) dans le panneau 18. Insérez le tiroir dans l’ensemble en appuyant gauche du tiroir (R), le panneau droit du tiroir (Q) et sur les leviers de dégagement des glissières et en Étagère le panneau arrière du tiroir (S).
Page 19
INSTRUCTIONS POUR L’ASSEMBLAGE INSTRUCTIONS POUR L’ASSEMBLAGE Installation de la tablette longue Installation au mur Remarque : Si la tablette longue (V) doit être coupée pour 21. À l’aide d’un détecteur de montants, repérez les tenir à l’intérieur de votre placard, coupez uniquement bordures des montants.
Page 20
INSTRUCTIONS POUR L’ASSEMBLAGE ENTRETIEN • Vérifiez périodiquement si les composants sont bien positionnés, en bon état et fermement Installation des tringles montés. 25. Insérez les tringles métalliques de 22 mm (X) dans les • Utilisez un linge doux et propre qui n’égratignera pas la surface lorsque vous époussetterez tringles métalliques de 25 mm (Y).
Page 21
DE PIÈCE de niveau. Panneau gauche de l’étagère *WSWS-CS1C/W/P/S/G/LWCKBW-1-HPL Panneau droit de l’étagère *WSWS-CS1C/W/P/S/G/LWCKBW-2-HPR Panneau supérieur de l’étagère *WSWS-CS1C/W/P/S/G/LWCKBW-3-HPT La tour de rangement Les emplacements des trous de Réinstallez les traverses de fixation Panneau arrière de l’étagère *WSWS-CS1C/W/P/S/G/LWCKBW-4-HPB ne s’installe pas au montage ne sont pas corrects.
Page 22
Support à tringle ouvert *WSWS-CS1C/W/P/S/G/LWCKBW-48-OPH Support à tringle fermé *WSWS-CS1C/W/P/S/G/LWCKBW-49-CPH Vis autotaraudeuse M4 de 15 mm *WSWS-CS1C/W/P/S/G/LWCKBW-47-15SS Quincaillerie complète *WSWS-CS1C/W/P/S/G/LWCKBW-48-CH Imprimé au Vietnam allen + roth® est une marque de commerce déposée de LF, LLC. Tous droits réservés. Lowes.com/allenandroth Lowes.com/allenandroth...
Page 23
• sophisticated • inspiring ARTÍCULOS #0339203, 0339204, 0339205, 0339206, 0810374, 2416433 allen + roth® es una marca registrada de LF, KIT DE ARMARIO COMPLETO LLC. Todos los derechos reservados. MODELOS #WSWS-CS1C, WSWS-CS1W WSWS-CS1P, WSWS-CS1S, WSWS-CS1G, LWCKBW ADJUNTE SU RECIBO AQUÍ...
Page 24
ÍNDICE CONTENIDO DEL PAQUETE Funcionamiento del sistema de cerrojo de leva..............44 Contenido del paquete......................45 Aditamentos.........................46 Información de seguridad....................48 Preparación........................48 Instrucciones de ensamblaje..................... 49 Cuidado y mantenimiento ....................59 Solución de problemas...................... 59 Garantía..........................61 Lista de piezas de repuesto ....................61 FUNCIONAMIENTO DEL SISTEMA DE CERROJO DE LEVA DETALLE A DETALLE B...
Page 25
ADITAMENTOS (no se muestran en tamaño real) ADITAMENTOS (no se muestran en tamaño real) Perno de Arandela de Arandela Cerrojo de Perno de leva Manija de la gaveta Abrazadera en L Perno de leva grande Tuerca cilíndrica 1/4 x 1-1/4 pulg seguridad plana leva grande...
Page 26
INSTRUCCIONES DE ENSAMBLAJE INFORMACIÓN DE SEGURIDAD Ensamblaje de la base Lea y comprenda completamente este manual antes de intentar ensamblar, usar o instalar el 1. Presione la palanca de liberación en los producto. Palanca de deslizadores (U) y retire el riel de deslizamiento. •...
Page 27
INSTRUCCIONES DE ENSAMBLAJE INSTRUCCIONES DE ENSAMBLAJE 4. Fije el panel de base derecho (I) al ensamblaje con las 7. Fije el panel de base izquierdo (H) al ensamblaje con espigas grandes de madera (HH) y los cerrojos de leva las espigas grandes de madera (HH) y los cerrojos de leva grandes (DD).
Page 28
INSTRUCCIONES DE ENSAMBLAJE INSTRUCCIONES DE ENSAMBLAJE 10. Fije el panel de repisa izquierdo (A) y el panel de 12. Cuidadosamente, apoye el ensamblaje de la repisa repisa derecho (B) al panel de repisa posterior (D) y al de costado. Inserte las tuercas cilíndricas (VV) y los extensor curvo frontal (E) o al extensor recto frontal (F) pernos de leva grandes (UU) en la parte inferior del (según cuál de estos se adapte al estilo de su armario)
Page 29
INSTRUCCIONES DE ENSAMBLAJE INSTRUCCIONES DE ENSAMBLAJE 15. Coloque el panel inferior de la gaveta (T) en el 18. Para colocar la gaveta en el ensamblaje, Repisa panel izquierdo de la gaveta (R), el panel derecho presione hacia abajo las palancas de liberación en de la gaveta (Q) y el panel posterior de la gaveta los rieles de deslizamiento y deslice la gaveta en (S).
Page 30
INSTRUCCIONES DE ENSAMBLAJE INSTRUCCIONES DE ENSAMBLAJE Instalación de los estantes largos Instalación colgante para pared Nota: si necesita cortar el estante largo (V) para 21. Con un detector de vigas, localice los bordes de las adaptarlo al espacio del armario, solo corte un lado del vigas de madera.
Page 31
INSTRUCCIONES DE ENSAMBLAJE CUIDADO Y MANTENIMIENTO Instalación de las varillas • Revise periódicamente para asegurarse de que todos los componentes estén ubicados de forma 25. Inserte las varillas de metal de 22 mm (X) en las varillas correcta, no presenten daños y de que estén firmemente conectados. de metal de 25 mm (Y).
Page 32
No puede colgar la Las ubicaciones de los orificios Vuelva a instalar los listones de Panel de repisa izquierdo *WSWS-CS1C/W/P/S/G/LWCKBW-1-HPL torre del armario en la de montaje no son las correctas. colgante para pared; asegúrese de Panel de repisa derecho *WSWS-CS1C/W/P/S/G/LWCKBW-2-HPR pared.
Page 33
Soporte de varilla abierto *WSWS-CS1C/W/P/S/G/LWCKBW-48-OPH Soporte de varilla cerrado *WSWS-CS1C/W/P/S/G/LWCKBW-49-CPH Tornillo autorroscante M4 x 15 mm *WSWS-CS1C/W/P/S/G/LWCKBW-47-15SS Todos los aditamentos *WSWS-CS1C/W/P/S/G/LWCKBW-48-CH Impreso en Vietnam allen + roth® es una marca registrada de LF, LLC. Todos los derechos reservados. Lowes.com/allenandroth Lowes.com/allenandroth...
