THE INDICATOR LAMP (Fig. 10)
Notice about fi lter cleaning
If the fi lter becomes clogged and suction power decreases,
the indicator lamp will fl ash.
And the main unit will make a pulsing sound.
However, this is not a sign of a fault.
If this happens, promptly empty the dust case and clean
the fi lter. (See Fig. 12, Fig. 13, and "MAINTENANCE AND
INSPECTION" on page 15.)
Notice about intake port blockage
If the intake port becomes blocked during use - for example
while vacuuming carpets - the main unit will make a pulsing
sound, the indicator lamp will fl ash. However, this is not a
sign of a fault.
Clear the blockage from the intake port if this happens.
NOTE
If running continuously when the fi lter becomes
clogged or the intake port becomes blocked, the
appliance will stop running by temperature protection
of the motor.
MAINTENANCE AND INSPECTION
WARNING
○ For inspection and maintenance, be sure to turn off the
switch and disconnect the battery.
○ Do not work with wet hands. May cause electric shock
or injuries.
1. Cleaning the fi lter
If the vacuuming effi ciency is poor even when the dust
case has been emptied, remove the fi lter and wash it
in cold or warm water. (The water should not be hot
to the touch.) After washing, dry out of direct sunlight.
(Fig. 14-a)
Alternatively, blow off any debris attached to the fi lter
from the inside toward the outside with an air gun or
something similar. (Fig. 14-b)
Air pressure: General pressure (about 0.6 MPa)
NOTE
○ Do not wash the fi lter in a washing machine.
○ Do not wash the fi lter in hot water or dry it by fi re.
○ Do not detach the fan fi lter and the fi lter holder.
○ Do not use an air gun or similar tool to clean the fi lter,
fan fi lter or the appliance itself. (Fig. 14-c)
Doing so could push dirt into the appliance and cause
malfunction.
2. Cleaning the fan fi lter
If there is dust on the fan fi lter, hold the cleaner with
the fan fi lter pointing downwards to keep dust from
entering the motor and lightly clean with a small brush
such as a used toothbrush. Do not brush vigorously.
(Fig. 15)
3. Inspecting the fl ooring nozzle
Inspect the fl ooring nozzle to confi rm that its blade is
not dislodged. If the blade is dislodged, press it in until
it catches on the projection.
Using with the blade dislodged may cause stains.
When replacing the blade, insert it starting from the
notch in the rail, and thread it along the groove. Ensure
there is no sagging throughout. (Fig. 16)
4. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws
be loose, retighten them immediately. Failure to do so
could result in serious hazard.
5. Maintenance of the motor
The motor unit winding is the very "heart" of the power
tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
6. Inspection of terminals (tool and battery)
Check to make sure that swarf and dust have not
collected on the terminals.
On occasion check prior, during and after operation.
CAUTION
Remove any swarf or dust which may have collected on
the terminals.
Failure to do so may result in malfunction.
7. Cleaning of the outside
When the tool is stained, wipe with a soft dry cloth
or a cloth moistened with soapy water. Do not use
chloric solvents, gasoline or paint thinner, as they melt
plastics.
8. Storage
Store the power tool and the battery in a place in which
the temperature is less than 40°C and out of reach of
children.
When storing the appliance in a vertical position, hook
the strap to a hanger.
NOTE
○ Do not store in a location where children can easily
reach or take out the appliance.
○ Do not store in a damp location or in an area exposed to
rainfall.
○ Do not store in direct sunlight or in a location where
temperatures may suddenly change
○ Do not store in a location with volatile materials that
could ignite or explode.
○ Do not stand the appliance against a wall without using
the strap to fi x it in place. (Fig. 17)
Failure to do so may result in damage from a fall.
○ Storing lithium-ion batteries.
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries with
a low charge may result in performance deterioration,
signifi cantly reducing battery usage time or rendering
the batteries incapable of holding a charge.
However, signifi cantly reduced battery usage time may
be recovered by repeatedly charging and using the
batteries two to fi ve times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries
dead and purchase new batteries.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
Important notice on the batteries for the HiKOKI
cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used
with batteries other than these designated by us, or
when the battery is disassembled and modifi ed (such
as disassembly and replacement of cells or other
internal parts).
