English
Switching OFF
Disconnect the battery
Prohibited action
HIGH mode
MID/LOW mode
OFF button
Battery
Lights ;
The battery remaining power is over 75%
Lights ;
The battery remaining power is 50%–75%.
Lights ;
The battery remaining power is 25%–50%.
Lights ;
The battery remaining power is less than 25%
Blinks ;
The battery remaining power is nearly empty.
Recharge the battery soonest possible.
Blinks ;
Output suspended due to high temperature.
Remove the battery from the tool and allow it to
fully cool down.
Blinks ;
Output suspended due to failure or
malfunction. The problem may be the battery
so please contact your dealer.
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains
the accessories listed on page 219.
Battery and battery charger are not included with this
product.
Standard accessories are subject to change without
notice.
APPLICATIONS
○ Light-duty vacuuming of dry surfaces
SPECIFICATIONS
1. Power tool
Model
Item
Voltage
Application
3 (HIGH)
Continuous
operating time
2 (MID)
(Battery: using
BSL36A18)
1 (LOW)
Suction Work Rate
Dust collecting capacity
Battery available for this
tool*
Dimensions (W × D × H)
Weight**
* Existing batteries (BSL3660/3626X/3626/3625/3620,
BSL18.... and BSL14.... series) cannot be used with this
tool.
** According to EPTA-Procedure 01/2014
The weight does not include accessories.
NOTE
Due to HiKOKI's continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
2. Battery (sold separately)
Model
Voltage
Battery capacity
Available cordless
products**
Available charger
* The tool itself will automatically switch over.
** Please see our general catalogue for details.
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger's power cord to the
receptacle.
When connecting the plug of the charger to a
receptacle, the charge indicator lamp will blink in red
(At 1- second intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the charger as shown in
Fig. 3 (on page 2).
3. Charging
When inserting a battery in the charger, the charge
indicator lamp will blink in blue.
When the battery becomes fully recharged, the charge
indicator lamp will light up in green. (See Table 1)
(1) Charge indicator lamp indication
The indications of the charge indicator lamp will be
as shown in Table 1, according to the condition of the
charger or the rechargeable battery.
12
R36DB
36 V
Dry type
Approx. 15 min
Approx. 30 min
Approx. 60 min
3 (HIGH) : Approx. 155 W
2 (MID) : Approx. 65 W
1 (LOW) : Approx. 35 W
560 mL
Multi volt battery
476 mm × 112 mm × 169 mm
1.6 kg (BSL36A18)
1.9 kg (BSL36B18)
BSL36A18
36 V / 18 V (Automatic Switching*)
2.5 Ah / 5.0 Ah
(Automatic Switching*)
Multi volt series, 18 V product
Sliding charger for lithium ion
batteries
