SPECIFICATIONS

Inputs Connector
CHANNEL A
CHANNEL B
CMR better than 45 dB on A and B channel inputs.
Mute level better than 87 dB @ 1 KHz .
Crosstalk between A and B channel better than 87 dB @ 1 kHz, and 76 dB @ 10 kHz.
Crosstalk between Left and Right channel better than 90 dB @ 1 kHz, and 75 dB @ 10 kHz.
Output Connector
Main
Monitoring Cinch
Phones
Jack 6,35
THD @ + 10 dBu (1 kHz) on main Outputs : 0.03 %.
Maximum Output level : + 27 dBu. + 26 dBu with a 600 Ohms charge.
Signal to Noise ratio : 93 dB (A weighted at nominal level). 113 dB (A weighted at clipping).
Bandwidth : 7 Hz to 70 kHz @ -1 dB.
Options:
AUF 200S.EE.
AUF 200S.ET.
AUF 200S.TE.
AUF 200S.TT.
BYP 200
All Inputs / Outputs, external remote Inputs and mains supply are RFI protected
Power supply :
Dimensions :
Weight :
RAMI
Type
Balanced
X L R
Balanced
X L R
Type
Balanced
XLR
Unbalanced
Unbalanced
Electronically balanced Inputs and Outputs.
Electronically balanced Inputs / Transformer balanced Outputs.
Transformer balanced Inputs / Electronically balanced Outputs.
Transformer balanced Inputs / Outputs.
Bypass, input A or B (internal selection) directly routed to the output.
(Security when mains absence)
230 Volts +/- 10 %
1 U 19" (483 x 44 x 230 mm)
4 kg
Impedance Sensitivity
-10 dBu / 245 mV à
15 K ohms
+ 12 dBu / 3,1 V
- 10 dBu / 245 mV à
15 K ohms
+ 12 dBu / 3,1 V
Impedance Nominal Level
+ 6 dBu / 1,55 Volts
40 Ohms
0 dBu / 0,775 mV
220 Ohms
0 dBu / 0,775 mV
220 Ohms
50/60 Hz
20
Clipping
+26 dBu / 15,5 V
+26 dBu / 15,5 V
Maximum Level
+ 26 dBu / 15,5 V
+ 20 dBu / 7,75 V
+ 20 dBu / 7,75 V
AUF200S
