GENERAL
Carefully read the following important information regard-
ing installation safety and maintenance. Keep this infor-
mation booklet accessible for further consultations. The
appliance has been designed for use in the ducting ver-
sion (air exhaust to the outside – Fig.1B), filtering ver-
sion (air circulation on the inside – Fig.1A) or with exter-
nal motor (Fig.1C).

SAFETY PRECAUTION

1. Take care when the cooker hood is operating simulta-
neously with an open fireplace or burner that depend on
the air in the environment and are supplied by other than
electrical energy, as the cooker hood removes the air
from the environment which a burner or fireplace need for
combustion. The negative pressure in the environment
must not exceed 4Pa (4x10-5 bar). Provide adequate
ventilation in the environment for a safe operation of the
cooker hood. Follow the local laws applicable for external
air evacuation.
Before connecting the model to the electricity net-
work:
- control the data plate (positioned inside the appliance)
to ascertain that the voltage and power correspond to
the network and the socket is suitable. If in doubt ask a
qualified electrician.
- If the power supply cable is damaged, it must be replaced
with another cable or a special assembly, which may be
obtained direct from the manufacturer or from the Technical
Assistance Centre.
2. WARNING !
In certain circumstances electrical appliances may
be a danger hazard.
A) Do not check the status of the filters while the
cooker hood is operating
B) Do not touch bulbs or adjacent areas, during or
straight after prolonged use of the lighting installation.
C) Flambè cooking is prohibited underneath the cooker
hood
D) Avoid free flame, as it is damaging for the filters
and a fire hazard
E) Constantly check food frying to avoid that the over-
heated oil may become a fire hazard
F) Disconnect the electrical plug prior to any mainte-
nance.
G) This appliance is not intended for use by young
children or infirm persons without supervision
H) Young children should be supervised to ensure they
do not play with the appliance
I ) There shall be adequate ventilation of the room
when the rangehood is used at the same time as appli-
ances burning gas or other fuels
L) There is a risk of fire if cleaning is not carried out
in accordance with the instructions
This appliance conforms to the European Directive EC/
2002/96, Waste Electrical and Electronic Equipment
(WEEE). By making sure that this appliance is disposed
of in a suitable manner, the user is helping to prevent
potential damage to the environment or to public health.
The symbol on the product or on the accompanying
paperwork indicates that the appliance should not be
treated as domestic waste, but should be delivered to a
suitable electric and electronic appliance recycling
collection point. Follow local guidelines when disposing
of waste. For more information on the treatment, re-use
and recycling of this product, please contact your local
authority, domestic waste collection service or the shop
where the appliance was purchased.

INSTALLATION INSTRUCTIONS

Assembly and electrical connections must be carried
out by specialised personnel.
ENGLISH
• Electric Connection
The appliance has been manufactured as a class II,
therefore no earth cable is necessary.
The connection to the mains is carried out as follows:
BROWN = L line
BLUE = N neutral
If not provided, connect a plug for the electrical load
indicated on the description label. Where a plug is pro-
vided, the cooker hood must be installed in order that the
plug is easily accessible.
An omnipolar switch with a minimum opening of 3mm
between contacts, in line with the electrical load and
local standards, must be placed between the appliance
and the network in the case of direct connection to the
electrical network.
• The minimum distance between the support surfaces
of the cooking pots on the cooker top and the lowest part
of the cooker hood must be at least 65 cm. If a connec-
tion tube composed of two parts is used, the upper part
must be placed outside the lower part. Do not connect
the cooker hood exhaust to the same conductor used to
circulate hot air or for evacuating fumes from other appli-
ances generated by other than an electrical source.Before
proceeding with the assembly operations, remove the
anti-grease filter(s) (Fig.9) so that the unit is easier to
handle.
In the case of assembly of the appliance in the suction
version prepare the hole for evacuation of the air.

• WALL FIXING

- Position the fixing template on the wall while maintaining
the minimum distance from the hob.
- Mark fixing holes D and cut them into the material (fig.
2A).
- Take guide rails E and brackets C and fix them to the
wall using screws F (fig. 2B). When carrying out the fixing
procedures, use only screws and screw anchors which
are suited to the type of wall (e.g. reinforced concrete,
plasterboard etc.).
- If the screws and screw anchors are supplied with the
appliance, make sure that they are suited to the type of
wall to which the hood must be fixed.
- Take the hood and (in line with our advice), with the help
of another person, thread the hood B along the guide
rails A (fig. 3).
- Align the hood with bracket C (fig. 4) and fix it in place
using screws E.
• FIXING DECORATIVE TELESCOPIC DUCTS
Make sure the electrical power supply is within the values
required by the decorative duct. If your appliance must
be installed as an extractor version or as a version with
an external motor, make sure an air exhaust hole is
prepared.
This product has been designed so that the duct fixing
bracket C(fig. 5) can be fitted to walls or ceilings.
When fixing the appliance to the wall, please consult
figure 5A.
- adjust the height of bracket C and use a pencil to mark
the 4 holes which should be made afterwards. Use the 4
screws D to fix the bracket to the wall.
When fixing the appliance to the ceiling, please consult
figure 5B.
- Place bracket C against the ceiling and use a pencil to
mark the 3 holes which should be made afterwards. Use
the 3 screws E to fix the bracket to the ceiling.
- Extractor hood: fix flexible hose H (not supplied) to the
air exhaust hole made previously (fig. 6).
- Filter hood: connect the flexible hose to the baffle
plate M and tighten screws P as indicated in (fig. 7), the
active carbon filters should be fitted to the extraction
assembly inside the hood (fig. 10). If the kit is not supplied,
order it from your local dealer as an accessory.
- Fix the flexible hose H (not supplied) over the connector
flange F (fig. 6 - 7). Place the decorative duct over the
bodywork.
Pull out the upper decorative duct Y as far as bracket C
and fix it in place using screws X (fig. 8).
