SPECIFICATIONS

Inputs
Send
Phone line
Standby
Outputs
Retun
Phone line
Bandwith :
Power supply :
Power :
Dimensions :
Weight :
RAMI
Connector Type
XLR et
Balanced
Sub-D 15 pts
RJ 11 Balanced
XLR Balanced
Connector Type
XLR et
Balanced
Sub-D 15 pts
Balanced
Sub-D 15 pts
Send: 300 Hz to 3500 Hz at -3dB
Return: 200 Hz to 3500 Hz at -3dB
230V +/- 10% 50/60 Hz
12 W
483 x 44 x 230 mm
4 kg
Nominal level
Impedance
+6 dBu / 1,55 V
15 KOhms
-10 dBu / 245 mV
600 Ohms
+6 dBu / 1,55 V
15 KOhms
Impedance Nominal Level
+6 dBu / 1,55 V
100 Ohms
-10 dBu / 245 mV
600 Ohms
25
Min Level Maxi Level
Impédance
- 4 dBu / 490 mV +26 dBu / 15,4 V
-26 dBu / 38 mV -2 dBu / 620 mV
-4 dBu / 490 mV +26 dBu / 15,4 V
Maximum Level
+26 dBu / 15,5 V
-6 dBu
with limiter
TEL400
