System Map: Front, Left & Right Views
1
2
6 7
8

Inserting Cards
into the Card
Reader \
9 10
Note that the cards
shouldbe inserted
with the read-able
side of the card fac-
ing upwards, as illus-
trated on the right.
Front
Left
4
3
5
Right
9
10
1. LED Indicators
2. Vent
3. HDMI-Out Port
4. *Powered USB 3.0 Port
*Toggle power to this port by using
Fn + power button (see Table 2
on page 8).
5. Mini DisplayPorts
6. S/PDIF-Out Jack
5
11 11
12
13
Figure 15
Front, Left & Right Views
7. Microphone Jack
8. Headphone Jack
9. Multi-in-1 Card Reader
10. SIM Card Reader (for
3G/4G USIM Cards)
11. USB 3.0 Ports
12. RJ-45 LAN Jack
13. Security Lock Slot

USIM Card Ejection
Simply press on the
SIM card to eject it,
however do not do
this while a connec-
tion is in progress.
If you do eject the card
while a 3G/4G con-
nection is ongoing,
you will need to shut
down the system, re-
insert the USIM card,
restart the system and
then reestablish the
3G/4G connection.
If you wish to change
SIM cards then you
will also need to shut
down the system, re-
insert the USIM card,
restart the system and
then reestablish the
3G/4G connection.
