• Do not change or modify anything on the Quadrocopter.
If you do not agree to these terms please immediately return
the complete Quadrocopter model in new and unused condi-
tion to the retailer.
Important information concerning Lithium Polymer re-
chargeable batteries
Lithium-Polymer (LiPo) rechargeable batteries are sig-
nificantly more sensitive than traditional alkali- or NiMH-re-
chargeable batteries normally used with radio control units.
Therefore the instructions and warnings have to be observed
in detail. In case of improper use of LiPo rechargeable batter-
ies there is a danger of fire. Always follow the manufacturers´
instructions if you dispose of LiPo rechargeable batteries.
Regulations on disposal for waste electrical and elec-
tronic equipment (WEEE)
This symbol, showing refuse bins with
a cross through them, denotes that
empty batteries, rechargeable batter-
ies, button cells, recharge able battery
packs, equipment batteries, disused
electrical equipment, etc. should not be disposed of in do-
mestic refuse, as they are harmful to the environment and
health. Please help to preserve environment and health and
talk to your children about the correct disposal of used bat-
teries and disused electrical equipment. Batteries and dis-
used electrical equipment should be handed in to the usual
collection points where they can be properly recycled.
Do not mix dissimilar battery types or employ new and used
batteries together. Empty batteries should be removed from
the product. Do not recharge non-rechargeable batteries
due to risk of explosion.
WARNING!
Rechargeable batteries should only be charged under adult
supervision.
Never leave the battery unattended while it is charging
Exhausted batteries are to be removed from the toy. Re-
chargeable batteries should be removed from the product
before charging. Supply terminal are not to be short-circuited.
Only use the batteries recommended or equivalent types.
If in regular use the charger must be examined for damage
to the cord, plug, covers and all other parts. If any signs of
damage are found the charger may only be used again after
repair work has been completed. The external flexible cable
or cord of this charger cannot be replaced: If the cord is dam-
aged the charger shall be scrapped.
The toy is only to be connected to Class II equipment bear-
ing the following symbol.
FCC statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, in-
cluding interference that may cause undesired operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
Guidelines and warnings for the use of LiPo recharge-
able batteries
• You have to charge the attached 3.7 V
LiPo rechargeable battery in a safe place and at a safe
distance to flammable material.
• Never leave the battery unattended while it is charging
• After a flight, the rechargeable battery has to cool down to
the ambient air temperature before charging it.
• You must always use the corresponding LiPo charging unit
(USB cable / remote control). In case of non-compliance
with these directions there is a danger of fire resulting in
a health risk and/or damage to property. NEVER use any
other battery charger.
• Should the rechargeable battery swell or deform while dis-
charging or recharging, you have to immediately stop charg-
ing or discharging the battery. Take the battery out as quickly
and carefully as possible and place it in a safe and open area
offside any inflammable material and watch it for at least
15 minutes. In case you continue charging or discharging a
battery which has already started to swell or deform there is
a danger of fire! Even in case of slight deforming or balloon-
ing the rechargeable battery has to be taken out of operation.
• Store the rechargeable battery at ambient temperature in a
dry place.
• Always recharge the battery immediately after use to
prevent its becoming deep discharged. Please make
sure to allow a pause of about 20 minutes between fin-
ishing the flight and recharging the battery. Recharge
the battery occasionally (suggested every 2-3 months).
Failure to treat the battery as described above can lead
to its becoming defective.
• When transporting or temporarily storing the rechargeable
battery the temperature should be between 5-50°C. If pos-
sible, do not store the battery or the model in a car and do
not expose it to direct sunlight. In case the battery is broiled
it can be damaged or catch fire.
Note: If the battery voltage/output is low you will recognise
that a considerable trim and/or controlling is necessary to
avoid that the Quadrocopter starts trundling. This usually
occurs before reaching a battery voltage of 3 V and it is a
good moment to end the flight.
Contents of package
1 x Quadrocopter
1
1 x Controller
1 x USB charging cable
1x 3,7 V, 1000mAh Rechargeable Battery
1x Lanyard
1 x Camera
1 x Landing feet including screws
1 x Smartphone holder including screws
1 x Set of replacement parts
1 x Screwdriver
6 x 1.5 V Mignon AA batteries
(non-rechargeable)
Fixing of the landing feet, the
camera and the smartphone holder
Using the screwdriver, fix the four landing feet on
2
the underside of the Quadrocopter, as shown in
the illustration.
Place the camera in its central mounting under-
3
neath the Quadrocopter. Plug the three-wire plug
in the left-hand and the five-wire plug in the right-
hand socket next to the mounting.
Using the screwdriver, fix the smartphone holder
4
in the middle on the aerial on the controller.
Recharging the LiPo rechargeable
battery
Make sure you only charge the LiPo rechargeable battery
supplied with the LiPo charging unit also supplied (USB ca-
ble and remote control). If you try to charge the rechargeable
battery with a different LiPo battery charger or any other bat-
tery charger, this might cause serious damage. Please care-
fully read the previous chapter with warnings and guidelines
on the usage of rechargeable batteries before proceeding.
Supply terminals are not to be short-circuited.
1000 mAh / 3,7 Wh You can charge the rechargeable battery fitted in the Quad-
rocopter with its USB charging cable from a USB port on a
computer:
Charging via computer:
5a
• Rechargeable batteries are to be removed
from the model before being charged.
• Connect the USB charging cable with the USB
port of a computer. The LED on the USB charger
cable lights green indicating that the charger unit
is correctly connected to the computer. If you
plug in a Quadrocopter with a discharged battery,
the LED on the USB charging cable no longer
lights up, showing that the Quadrocopter battery
is being charged. The USB charging cable and
the charging socket on the Quadrocopter are de-
signed to make incorrect connection impossible.
• It takes about 60 minutes to recharge a dis-
charged battery (but NOT a deep-discharged
one). When the battery is fully charged, the
LED display on the USB charger cable lights up
green again.
5b
Note: when supplied, the lipo-battery is already partially
charged. So the first charging cycle may well take less time.
It is essential to follow the connection sequence given
above!
Undo the plugged connection on the Quadrocopter
when you are not using the Quadrocopter. Failure to ob-
serve this precaution may cause battery damage!
Inserting the batteries in the
remote control
6
Frequency bind between model
and remote control
7
Range of functions of the
remote control
8
8
To insert the rechargeable battery, open the bat-
tery compartmentunderneath the Quadrocopter.
Push the battery into the compartment and plug
it into the socket there. Then reclose the compart-
After use: Undo the plugged connection
ment.
on the Quadrocopter when you are not using
the Quadrocopter. Failure to observe this pre-
caution may cause battery damage!
Open the battery compartment with a screwdriver
and insert the batteries in the remote control.
Please keep in mind the correct polarity. After
having closed the compartment you can check all
functions of the remote control with the help of the
power-switch on the front.
With the power switch turned ON and functioning
correctly, the top centre LED on the remote con-
trol will light up red.
When the control LED flashes rapidly, the batter-
ies in the controller must be changed.
The Carrera RC Quadrocopter and the remote
control are frequency bound at purchase. If initially
there are any problems with communication be-
tween the Carrera RC Quadrocopter and the remote
control, please carry out a new frequency bind.
• Connect the battery in the model.
• Switch the model ON at the ON/OFF switch.
• WARNING! Immediately after switching it on,
place the Quadrocopter on a flat and level
surface. The gyro-system will then set itself
automatically.
• The LEDs on the quadrocopter now flash rhyth-
mically.
• Switch on the controller at the ON/OFF switch.
• Push the left-hand joystick, i.e. the throttle lever,
right to the top, then fully downwards into the
zero position.
• The binding has now been successfully estab-
lished. The LED on the controller now lights
continuously.
1. Aerial
2. Power switch (ON / OFF)
3. Control LED
4. Gas
Circling
5. Forwards / backwards
right / left banking
6. Trimmer for right / left banking
7. Trimmer for forwards / backwards
8. Trimmer for rotation
9. Looping Button
10. Beginner/Advanced switch (30% / 60% / 100%)
11. "Return home" button
12. "Activate compass" button
13. Battery compartment
14. Smartphone holder (Contains no smartphone)
15. "LED lights ON/OFF" button
16. Settign wheel to adjust camera angle
