DESCRIPTION
D
escription of the repeater.
INSTALLATION
D
etail of the repeater installation.
Install the repeater
To avoid damage, the repeater must be firmly fixed.
The repeater can be installed on a DIN guide
(6 elements), pressing it lightly.
To extract the repeater from the DIN guide,
use a plain screwdriver to lever the flange as
shown in the picture.
in a dry and protected place without risk of drip or water projections.
The installation or modification the
The installation and handling of the
To install the
Autodiagnostic LEDs.
Reset button 'P1', for short-circuit Bus
(riser where repeater is connected).
Label.
Bus connection block.
Power supply input
(with FA-V2Plus power supply).
DIN rail latch release.
performed in the absence of electrical current.
performed by authorized personnel.
repeater directly on the wall, drill two holes
of 6mm. and insert the wallplugs. Fix the
with the specified screws.
DIN 46277
repeater, must be
repeater must be
repeater
47
