SmartCharge
6
Operation - Battery Charging
4 Pressing the Auto Charge function will automatically apply the fastest charge rate the battery connected can safely take.
With this mode selected 'AUTO' is displayed on the LCD display
5. Charging is complete when 100% is displayed on the LCD screen
Battery Charging Mode
For standard battery charging at temperatures over 5°C
Increases the battery voltage to 14.4v (standard vehicle) or 14.6v (Start/Stop vehicle).
Winter Mode
Used for charging batteries at low temperatures (-20°C to +5°C). Increases the battery voltage to 14.6v
(standard vehicle) or 14.8v (Start/Stop vehicle).
Recondition Mode
Applies a controlled increased charging voltage to allow recovery of deeply discharged batteries
Maintenance Mode
Applies to low 0.8A charging rate, ideal for long term seasonal connection
7
Operation - Battery Analysing
RSC608/RESC608
RSC612/RESC612
* Default charging modes
Battery analysing modes operate with and without AC mains supply. Connecting the battery clips to the battery
automatically activates the charger
1. Press the navigation arrows to select the battery charging icon and press SET.
TEST SET
Battery Analysing
2. Press the navigation arrows to select the required charging mode and press SET.
Pressing EXIT at any stage takes you to the first stage of the menu process.
Battery Capacity is RSC612/RESC612 only.
Battery Voltage Battery Start Power
*
*
Alternator Output
6
Battery Capacity
-
