Pulmic ANIMAL TRACK Mode D'emploi page 18

6. Pass the two bar hoses through the clamping clamps, (figure 7).
7. Operate the On / OFF switch for two seconds to check that it works, (figure 8).
8. Fill the tank with water (50 liters)
9. Ensure that the hydraulic connections are correct, place the desired nozzles in working position,
and perform the speed test.
10. Check that the battery is never discharged, when the yellow bar is activated it indicates that
the battery has reached its minimum level of charge and must finish and recharge. When the
red bar is activated, it indicates that the battery charge level is below the minimum and may
damage it if it does not stop and recharge (figure 8).
Clamping clamp
Figure 7
Charge indicator
Figure 8
18 18
Return
Absorption and
drainage
Switch on/off
Connect the plug to
the base of the charger
