E. Install Air Deflectors top and bottom. Center (left and
right) the Air Deflectors above and below the installed
BACK FRAME. Secure Air Deflectors with 4 SCREWS (G).
See Figure 12. Mark holes and pre-drill the wood cleats
with
1
⁄
" drill bit.
16
FIGURE 12
F. FRONT FRAME INSTALLATION: Place the FRONT
FRAME onto the BACK FRAME and align ball studs
and receivers. Secure the FRONT FRAME to the BACK
FRAME by firmly pushing the FRONT FRAME onto the
BACK FRAME, engaging the 4 snap attachments. See
Figures 13-14.
SHARP ELECTRONICS CORPORATION
100 Paragon Drive • Montvale, New Jersey 07645 • U.S.A.
SHARP ELECTRONICS OF CANADA LTD.
335 Britannia Road East • Mississauga, Ontario L4Z 1W9 • Canada
Snap
Attachment
For any other assistance or information about this kit,
in USA please call Sharp's Customer Assistance Center at
E 8
FIGURE 13
FIGURE 14
1-800-BE-SHARP (1-800-237-4277)
In Canada, call 905-568-7140
