Empire FRBC Instructions D'installation Et De Fonctionnement

IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
INTRODUCTION
This ECS's remote control system was developed to provide
safe, reliable, and user-friendly remote control system for
gas heating appliances.
The system can be operated manually from the transmitter.
The system operates on one of 255 security codes that are
programmed into the transmitter at the factory.
The transmitter operates on a 12V battery (included) made
specifically for remote controls and electronic lighters.
Install the 12V battery supplied with the unit into the battery
compartment.
TRANSMITTER
It is recommended that AKALINE batteries always be
used for longer battery life and maximum operational
performance.
The transmitter has ON and OFF functions that are activated
by pressing either button on the face of the transmitter.
When a button on the transmitter is pressed, a signal light
on the transmitter illuminates briefly to verify that a signal
has been sent. Upon initial use, there may be a delay of
three seconds before the remote receiver will respond to
the transmitter. This is part of the system's design. If the
signal light does not illuminate, check the position of the
transmitter's battery.
17808-5-0220
INSTALLATION AND OPERATING
INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE
Empire Comfort Systems Inc. • Belleville, IL
FRBC
REMOTE RECEIVER
The remote receiver operates on 4 AA-size 1.5V batteries. It
is recommended that ALKALINE batteries be used for longer
battery life and maximum microprocessor performance.
IMPORTANT: New or fully charged batteries are essential
for proper operation of the remote receiver.
The remote receiver houses the microprocessor that
responds to commands from the transmitter to control
system operation. The remote receiver has a 3-position
slide switch for selecting the MODE of operation: ON/
REMOTE/OFF
• With the slide switch in the ON position (toward the
LEARN button), the system will remain on until the slide
switch is placed in the OFF or REMOTE position.
• With the slide switch in the REMOTE position
(centered), the system will only operate if the remote
receiver receives commands from the transmitter.
• With the slide switch in the OFF position (away from the
LEARN button), the system is off.
• It is suggested that the slide switch be placed in the
off position if you will be away from your home for
an extended period of time. If the remote receiver
is mounted out of children's reach, placing the
slide switch in the OFF position also functions as
a safety "lock-out" by both turning the system off
and rendering the remote receiver inoperative.
