5.

RAIL SPLITTINGS

700W
600W
500W
400W - 300W
6.

DIMENSIONS

L x W x H (mm): 150 x 150 x 86
7.

DISTRIBUTION AND PIN ASSIGNMENT

24 PIN ATX power connector
Pin Signal
1 +3�3VDC
2 +3�3VDC
3 COM
4 +5VDC
5 COM
6 +5VDC
7 COM
8 PWR_OK
9 +5VSB
10 +12VDC
11 +12VDC
12 +3�3VDC
12V1
24pin, drives, PCIe 1+2
24pin, drives, PCIe 1
24pin, drives, PCIe
Pin Signal
+3�3VDC
13
+3�3Vdef�sense
14 -12VDC
15
16 PS_ON/OFF
17
18
19
20
21 +5VDC
22 +5VDC
23 +5VDC
24
P4+4, PCIe 3+4
P4+4, PCIe 2
COM
COM
COM
COM
COM
12V2
P4+4
