General Information

List of Features

Your TV is designed with the latest technology.
This TV is a high-performance unit that includes the following special features:
Easy-to-use remote control
Easy-to-use on-screen menu system
Automatic timer to turn the TV on and off
Adjustable picture and sound settings that can be stored in the TV's memory
Automatic channel tuning for up to 194 channels. (Air : 69 , STD : 125 )
A special filter to reduce or eliminate reception problems
Fine tuning control for the sharpest picture possible
A built-in multi-channel sound decoder for stereo and bilingual listening
Built-in, dual channel speakers
Headphone jack for private listening

List of Parts

Please make sure the following items are included with your LCD TV.
If any items are missing, contact your dealer.
Remote Control (BN59-00429A)
& Batteries (AAA x 2)

How to Adjust the Stand

(1)

How to Adjust the Angle of the TV

(1) Angle adjustment when using the
TV on its stand.
When you adjust the stand, press the "PUSH" button on the back of the stand.
1. Figure (1) shows the adjustment angle (0°~13°) when you use the LCD on its stand.
Excessive tilting can turn the LCD TV over which may cause damage.
2. Figure (2) shows the adjustment angle (13°~80°) when you convert the LCD from stand-based use to wall-mount.
3. Figure (3) shows the adjustment angle (0°~10°) when you mount the LCD TV to a wall.
You will hear a "Click " sound when changing the angle from 1 to 2 or 3 to 2.
Power Cord
(3903-000085)
(2)
PUSH button
(2) Angle adjustment when converting from
Stand to Wall mount (1
English-2
Wall Mount kit
(BN96-01270A)
1. Place the front of the TV onto a soft cloth or
cushion on a table as in Figure (1).
- Align the TV bottom along the table edge.
2. Press on the center of the TV back.
Adjust the stand as in Figure (2) while pressing
the "PUSH" button on the back of the stand.
3. Place the TV on the table so that the TV sits
safely.
When you adjust the stand, press the "PUSH" button
on the back of the stand.
(3) Angle adjustment when LCD
3, 3 1)
Owner's Instructions
TV is wall-mounted
