Introduction
We recommend that you entrust the installation, adjustment
and regular maintenance to a specialist bicycle shop. Improper
intervention can lead to damage of the scooter or to an accident
with serious health consequences.
If you are technically capable, do not worry; this manual
contains all the information you need to help you assemble
your new scooter.
Send your questions, comments and suggestions for
improvement of our products by e-mail to: info@yedoo.eu.
More information from the
world of scooters and the list
of distributors can be found at
www.yedoo.eu.
EN
Installation manual
1.
The installation is the same for
all three models (Wzoom, Tidit, Mau),
it differs only in minor details
(see additional pictures).
Installing the front wheel
Loosen both nuts
4.
Make sure that the pad tip fits into the
correct slot and then tighten both nuts.
6 7
2. 3.
First check that the front fork of the Insert the wheel into the front fork so it
scooter is aligned correctly (the V-brake is exactly in the middle. Caution: When
shoulders should be pointing forwards inserting the wheel, ensure that the
towards the front of the scooter), then arrow on the tyre sidewall points in the
release the brake cable from the guide. direction of rotation when the scooter
is rolling forwards.
5. 6.a
Handlebars installation Insert the stem into the frame tube of
the scooter and adjust the handlebar
First loosen the stem screw, then install height taking care not to position it
the handlebars into the position as seen above the marked line, see pic. 6.b.
in the picture, then tighten the screws Make sure that the handlebars are
only slightly so you can adjust the angle straight and then tighten the screw
of the handlebars later on. on the stem.
(This step applies only for models
Wzoom and Tidit)
Direction
of rota-
tion
