Elpro 12 EVO
Note well: the installation of this electronic control board requires a speci c technical knowledge and must be carried out by
professionally quali ed people and habilitated according to the safety norms in force. It is important that these instructions be
!
carefully read and followed to avoid that the electronic control board be used and/or installed in the wrong way.
Elpro 12 EVO has been designed and constructed to control NYOTA 115 EVO electromechanical operators for sliding gates
(including the previous versions of them). Any other use or application, di erent from that speci ed in this manual is strictly
prohibited.
Meccanica Fadini declines any responsibility for damage caused to properties or persons due to possible incorrect installations
or failure of the system to comply with the applicable regulations; it is compulsory that the machinery directive 2006/42/CE be
implemented. Maintenance or inspections to assess the product status must be carried out by quali ed and professionally
trained technicians.
Before any servicing is made to the board, disconnect mains power supply. It is also recommended that the Safety Norms
manual be read, available from Meccanica Fadini on request. The manufacturing company does not take any liability for
improper use of the electronic control board.
CE DECLARATION OF CONFORMITY of the manufacturer:
Meccanica Fadini snc (Via Mantova, 177/A - 37053 Cerea - VR - Italy) declares under own responsibility that Elpro 12 EVO complies with the
2006/42/CE Machinery Directive, and also that it is sold to be installed in an "automatic system", along with original accessories and components as
indicated by the manufacturing company. The manufacturer is not liable for possible incorrect use of the product. The product complies with the
following speci c norms: Low Voltage Directive 2014/35/UE, Electromagnetic Compatibility Directive 2014/30/UE. In order to certify the product, the
Manufacturer declares under own responsibility the compliance with the EN 13241-1 PRODUCT NORMS.
General description: Elpro 12 EVO electronic board has been produced in order to provide an ideal solution to the control of the sliding gate
operator Nyota 115 EVO (including the previous versions), and incorporates self-learning programming of the gate cycle, encoder input, electronic
brake and slowdown in opening and closing phases.
Power supply: 230 V ±10% 50 Hz single-phase.

IMPORTANT:

!
- The control board should be installed in a sheltered, dry place inside its own protection box.
- Make sure that power supply to the electronic control board is 230 V ±10%.
- Make sure that power supply to the electric motor is 230 V ±10%.
- In case of distances wider than 50 meters, increase the wire section.
- Fit the power supply to the control board with a 0,03 A high sensibility, magneto-thermal circuit breaker.
- For the power supply, electric motor and asher use 1,5 mm² section wires up to 50 m of distance.
- For the limit switches, photocells, command switches and accessories use 1 mm² section wires.
- If no photocells are used bridge terminals 1 and 2.
- If no stop button is used bridge terminals 3 and 6.
N.W.: for applications such as lights control, CCTV, etc. use solid state relays to prevent intereference with the microprocessor.
TROUBLE SHOOTING IN CASE OF FAILURE:
- Make sure that power supply to the electronic control board is 230 V ±10% 50 Hz.
- Make sure that power supply to the electric motor is 230 V ±10% 50 Hz.
- In case of distances wider than 50 meters, increase the wire section.
- Check the fuses.
- Check all the N.C. contacts in the control board.
- Make sure that no voltage drop is occurring between control board and electric motor.
ELECTRONIC CONTROL BOARD FOR NYOTA 115 EVO
9
