AVLink Set Key Parts Illustration
Yagi antenna
connection (for
1072 cable 10dBi)
Manual/Loop switch
CH dip lock switch
Receiving channel switch
Wireless AVLink for indoor range extension (Art. nr 1092)
Flat antenna holder
Mounting foot for flat antenna
Transmitting channel
indicator
Flat antenna T Connector male head
Connector female head
Other parts included in the AVLink Set
17
Transmitting
channel switch
Transmitting
black antenna
(5dBi)
Power socket
(5V)
A/V out (for TV)
Receiving channel indicator
Antenna cable
