6.

DIMENSIONS

86mm
7.

DISTRIBUTION AND PIN ASSIGNMENT

24 PIN ATX power connector
Pin Signal
1 +3�3VDC
2 +3�3VDC
3 COM
4 +5VDC
5 COM
6 +5VDC
7 COM
8 PWR_OK
9 +5VSB
10 +12VDC
11 +12VDC
12 +3�3VDC
34
160mm (450-650W) | 170mm (750-1000W)
Pin Signal
+3�3VDC
13
+3�3Vdef�sense
14 -12VDC
15 COM
16 PS_ON/OFF
17 COM
18 COM
19 COM
20
21 +5VDC
22 +5VDC
23 +5VDC
24 COM
