EN
Always check that the power supply
corres ponds to the voltage on the rating
plate.
Your machine is double insulated;
therefore no earthwire is required.
Replacing cables or plugs
Immediately throw away old cables or plugs
when they have been replaced by new ones. It is
dangerous to insert the plug of a loose cable in
the wall outlet.
Using extension cables
Only use an approved extension cable suitable
for the power input of the machine. The minimum
conductor size is 1.5 mm
reel always unwind the reel completely.
3. Assembly
Prior to mounting an accessory always
unplug the tool.
Assembling the handle
Fig. 2
The handle is suitable for either left or
right-handed use.
• Install the handle in such way that the holes
match the screwholes on the machine.
• Tighten the handle with the bolts and
hexagon key.

Assembling accessoires

Fig. 3
• Press the spindle lock
• Screw and tighten the pad holder on the spindle
• Depress the spindle lock
• Mount the polishing pad onto the pad holder.

Accessoires

Fig. 4
Pattern felt (1)
This is used for sanding and polishing new paints
and plastics.
Fiber pad (2)
This is used in combination with other pads.
8
. When using a cable
2
Polishing pad (3)
In combination with the fiberpad, this is used for
high lustre polishing and waxing. The plastified layer
inside assures the maximum use of the used wax.
Wool polishing pad (4)
This is used for a high gloss finish. To be used in
combination with the fiber pad.
4. Use
Always follow the safety instructions and
keep to the applicable regulations.
• Hold the machine away from the workpiece
when turning it on and off.
• Always first turn the machine off after use
before removing the plug from the socket.
Speed control
Fig. 5
The speed of the disc can be controlled with the
rotary knob on top of the handle.
The higher the position, the higher the speed.
When applying the wax and polishing do not start
at a high speed.
Switching on and off
Fig. 6
• This machine is equipped with a safety
switch.
• Start the machine by pressing the "lock off"
button (to disengage the switch) and switch
on the machine.
Switch Off
Release the switch.
The polisher will continue to run after it is
turned off.
Only lay the machine down once the motor
has completely stopped turning. Do not put the
machine on a dusty surface. Dust particles can
penetrate the machine.
Never use the spindle key to stop the
motor turning.
