Fuse Replacement; Mounting Diagram - Chauvet DJ Intimidator Wave 360 IRC Manuel De Référence

Intimidator Wave 360 IRC QRG
AC Power
Power Linking

Fuse Replacement

Mounting

Mounting Diagram

Intimidator Wave 360 IRC has an auto-ranging power supply that can work with
an input voltage range of 100–240 VAC, 50/60 Hz.
To eliminate wear and improve its lifespan, during periods of non-use
completely disconnect from power via breaker or by unplugging it.
Power linking is accomplished when products are daisy chained together through
their Power In and Power Out sockets, so that many products can be powered from
one outlet.
For the maximum number of Intimidator Wave 360 IRC products that can be
power linked at 120 V or at 240 V, see the User Manual or the label on the
product. The User
http://www.chauvetlighting.com.
1. Disconnect the product from power.
2. With a flat-head screwdriver, unscrew the fuse holder cap from
the housing.
3. Remove the blown fuse.
4. Replace with a fuse of the same type and rating.
5. Screw the fuse holder cap back in place and reconnect power.
Disconnect the product from power before replacing the fuse.
Before mounting this product, read the
and one safety cable per product. Make sure the mounting clamps are capable of
supporting the weight of the product. For the Chauvet line of mounting clamps, go to
the Chauvet website at https://www.chauvetdj.com/products/category/accessories/.
Hanging/Mounting
Bracket
Safety
Cable
Manual is available
Safety Notes. Use one or two mounting points
4
at the Chauvet
Mounting Clamp
Rubber
Feet (x4)
for Floor
Mounting
EN
website
