9.1 Selection aid for slots
SpotClip-Kit 150 slot
1
2
3
4
5
6
SpotClip-Kit 240 slot
1
2
3
4
5
6
All dimensions in mm. We reserve the right to make technical changes without
notice.
Operating instructions • SpotClip-Kit • 11-2015
Min. Ø - max. Ø installation hole
100 - 170
120 - 190
140 - 210
160 - 230
180 - 250
200 - 270
Min. Ø - max. Ø installation hole
170 - 210
190 - 230
210 - 250
230 - 270
250 - 290
270 - 310
