Your safety, and the safety of others, is very important. To help you make informed decisions about safety,
we have provided installation and operating instructions and other information on labels and in this guide.
This information alerts you to potential hazards that could hurt you or others. It is not possible to warn you
about all potential hazards associated with this product, you must use your own good judgment.
CARELESS INSTALLATION AND OPERATION CAN RESULT IN SERIOUS INJURY OR EQUIPMENT
DAMAGE. READ AND UNDERSTAND ALL SAFETY PRECAUTIONS AND OPERATING INSTRUCTIONS
BEFORE INSTALLING AND OPERATING THIS PRODUCT.
This guide identifies potential hazards and has important safety messages that help you and others avoid
personal injury or death. WARNING and CAUTION are signal words that identify the level of hazard. These
signal words mean:
WARNING signals a hazard that could cause serious injury or death, if you do not follow
recommendations.
follow recommendations.
This guide uses NOTICE to call attention to important mechanical information, and Note: to emphasize general
information worthy of special attention.
Failure to observe these instructions could lead to severe injury or death.
Always Read the Plow Operator's Manual, the Winch Operator's Manual and all warning labels before operating.
Always use extreme caution when drilling on any vehicle. Make sure that all fuel lines, brake lines, electrical
wires, and other objects are not punctured or damaged when/if drilling on the vehicle. Thoroughly inspect the
area to be drilled (on both sides of material) prior to drilling, and relocate any objects that may be damaged.
Failure to inspect the area to be drilled may result in vehicle damage, electrical shock, fire or personal injury.
Always wear safety glasses when installing this kit.
Always use extreme caution when cutting and trimming during fitting.
Always remove jewelry and wear eye protection.
Always use appropriate and adequate care in lifting components into place.
Always insure components will remain secure during installation and operation.
Always tighten all nuts and bolts securely, per the installation instructions.
Always operate the vehicle at a walking speed with the blade installed. Never exceed 5 mph (8 km/h), even with
blade up.
Always plow cautiously, impact with hidden or stationary object may cause the vehicle to stop suddenly or go out
of control.
Never operate the vehicle on slopes greater than 10 degrees with the plow installed.
Never stand or ride on the plow.
Always stay clear of moving parts and joints. Always keep others away when operating or adjusting plow.
Always perform regular inspections and maintenance on the plow mechanism, fasteners, cable and related
hardware.
Always replace all worn or damaged parts before operating.
Never operate this WARN product with damaged or missing parts.
Always drive slowly over bumpy and rough terrain. Driving at speeds that cause the plow to bounce while in the
up position can cause the winch to back-drive, causing the plow to work its way down. This may result in the plow
impacting a stationary object and cause damage to the vehicle and operator injury or death.
Always drive at speeds such that the plow does not bounce and be aware of the plow position while driving at all
times.
Never raise the top of the plow above the headlights of the ATV, as it may damage the vehicle and plow.
WARN® INDUSTRIES
INSTALLATION INSTRUCTIONS
Yamaha Rhino Plow Mounting Kit
Application: Yamaha Rhino 08+
CAUTION signals a hazard that may cause minor to moderate injury, if you do not
INJURY HAZARD
WARN Part Number: 79815
WARNING
PAGE 1
79816A5

Publicité

Chapitres

Table des Matières
loading

Sommaire des Matières pour Warn 79815

  • Page 1 This information alerts you to potential hazards that could hurt you or others. It is not possible to warn you about all potential hazards associated with this product, you must use your own good judgment.
  • Page 2: Table Des Matières

    5/16” diameter bolt and nuts: 12 ft-lbs (16.5 N-m) 10mm diameter bolts and nuts 30 ft.lbs (40.7 N-m) 12mm diameter bolts an nuts 55 ft-lbs (74.6 N-m) WARN® INDUSTRIES PAGE 2 79816A5...
  • Page 3: Parts List

    10mm dia nylon lock nut 35136 Pin, with retainer 82466 Strap * C1 61461 U-bolt 2002 5/16” Lock Nut 2079 5/16” Nut 1402 5/16” Lock Washer 1324 5/16” Flat Washer * For use with WARN front brush guard only WARN® INDUSTRIES PAGE 3 79816A5...
  • Page 4: Installation

    Do not tighten at this time. See Figure 5. Note: Fasteners are not the same length. The shorter fasteners go to the mounting location on the motor side of the winch. Figure 3 WARN® INDUSTRIES PAGE 4 79816A5...
  • Page 5 See Figure 7. B2,B3,B4,B5 Fasteners supplied with winch 11. Install fasteners (B6, B7) in the rear location. See Figure 9. Figure 6 Install Front Fasteners - Bottom view of plow mount as- sembled to bumper WARN® INDUSTRIES PAGE 5 79816A5...
  • Page 6 Figure 7 Place Bumper on vehicle 13. Tighten all fasteners to torque specification listed. Figure 8 Install fasteners 14. See Warn plow push tube instruction manual for installing plow mount flange (A3). See Figure 11. B6,B7 Figure 9 Install Shims WARN®...
  • Page 7: Operation

    Connect the termination strap to the front bumper. The loop of the strap should be place as high as possible on the bumper. See Figure 13. See Fig- ure 15 when connecting to a WARN front brush guard. Figure 12 WARN®...
  • Page 8 This will aid in the next connection on the plow assembly. Figure 14 Figure 15 WARN® INDUSTRIES PAGE 8 79816A5...
  • Page 9: Tips/Troubleshooting

    Quick Release Pin kit 2x 35136 81866 Plow Mount Flange kit 1x 79965 Contact your nearest WARN Dealer to order. To find a dealer nearest you, please call the WARN Dealer locator line at 1 800-910-1122 WARN® INDUSTRIES PAGE 9 79816A5...
  • Page 10 Remplacez toujours toutes les pièces usées ou endommagées avant l’utilisation.  Ne faites jamais fonctionner ce produit WARN avec des pièces endommagées ou manquantes.  Conduisez toujours lentement sur les terrains cahoteux ou accidentés. Le fait de conduire à des vitesses qui secouent la lame alors ...
  • Page 11: Outils Requis

    Boulon et écrous de 10mm de diamètre : 40,7 N-m (30 pi-lb) Boulon et écrous de 12mm de diamètre : 74,6 N-m (55 pi-lb) Boulon et écrous de 5/16 po de diamètre : 16,5 N-m (12 pi-lb) WARN® INDUSTRIES PAGE 11 79816A5...
  • Page 12: Liste Des Pieces

    Boulon en U 2002 Écrou de blocage 5/16 po 2079 Écrou 5/16 po 1402 Rondelle de blocage 5/16 po 1324 Rondelle plate 5/16 po * Pour une utilisation avec une grille de protection avant WARN seulement WARN® INDUSTRIES PAGE 12 79816A5...
  • Page 13: Installation

    (A1). Utilisez les fixations fournies avec le kit de treuil. Ne serrez pas pour l’instant. Voir figure 5. Remarque : Les fixations n’ont pas la  même longueur. Les fixations les plus  courtes sont destinées à l’emplacement de montage du côté moteur du treuil. Figure 3 WARN® INDUSTRIES PAGE 13 79816A5...
  • Page 14: Installation (Suite)

    Voir Figure 7. B2,B3,B4,B5 Fixations fournies avec le treuil 11. Installez les fixations (B6, B7) à l’emplacement ar- rière. Voir Figure 9. Figure 6 Install Front Fasteners - Bottom view of plow mount as- sembled to bumper WARN® INDUSTRIES PAGE 14 79816A5...
  • Page 15 Figure 8 Installez les fixations 13. Consultez le manuel d’instructions du tube pous- soir Warn au sujet de l’installation de la bride de kit de montage de lame (A3). Voir Figure 11. B6,B7 Figure 9 Installez la bride de kit de montage de lame WARN®...
  • Page 16: Fonctionnement

    La boucle de la bande doit être placée aussi haut que possible sur le pare-chocs. Voir figure 13. Voir la figure 15 dans le cas d’une connexion à une grille de protection avant WARN. Figure 12 WARN® INDUSTRIES PAGE 16...
  • Page 17 Lorsque vous retirez la lame de son kit de montage, placez un bloc sous la base du tube poussoir pour maintenir l’ensemble à la hauteur de la con- nexion. Ceci facilitera la connexion suivante de la lame. Figure 14 Figure 15 WARN® INDUSTRIES PAGE 17 79816A5...
  • Page 18: Conseils Et Dépannage

    Communiquez avec le concessionnaire chez qui vous avez fait l’acquisition du kit. Appelez un des centres de service autorisés WARN indiqués sur la garantie qui accompagne le kit. Veuillez avoir les informations suivantes à portée de main avant d’appeler : numéro de pièce (listé sur le devant des instructions), date d’achat, marque, modèle et année du VTT.
