AC Power
This product has an auto-ranging power supply that works with an input voltage range of 100 to 240 VAC, 50/60 Hz.
To eliminate wear and improve its lifespan, during periods of non-use completely disconnect the
product from power via breaker or by unplugging it.

Power Linking

For the maximum number of Intimidator Spot 360 products that you can power link at each voltage, see the User Manual
or the sticker on the product.
Fuse Replacement
1. Disconnect the product from power.
2. Using a flat-head screwdriver, unscrew the fuse holder and pull straight out.
3. Remove the blown fuse from the holder and replace with a fuse of the exact same type and rating.
4. Re-insert the fuse holder and reconnect power.
Mounting
Before mounting this product, read the

Mounting Diagram

Control Panel Description
Button Function
<MENU> Exits from the current menu or function
<UP> Navigates upwards through the menu list and increases the numeric value when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function
<ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function
Intimidator Spot 360 QRG Rev. 4
QUICK REFERENCE GUIDE
Safety Notes.
Mounting Clamp
(such as CLP-15 from
Chauvet)
Safety Cable
(such as CH-05 from
Chauvet)
Hanging
Bracket
Feet for Floor
Mounting (x4)
