Guía de Cableado
Existen varias formas de conectar el subwoofer Resolv RXA, dependiendo de su
instalación específica. Para la conexión de su sistema de monitores, consulte los
siguientes diagramas de cables.
RCA
Pin 2 (hot)
Pin 3 (cold)
Pin 1 (shield)
Tip (+Signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Unbalanced ¼" Connector
Pin 2 (hot)
Pin 1 (shield)
Pin 3 (cold)
Balanced ¼" Connector
Pin 2 (hot)
Pin 1 (shield)
Pin 3 (cold)
40
Male XLR
Ring (-Signal)
Balanced ¼" Connector
Unbalanced ¼" Connector
Male XLR
Male XLR
Shield & Cold to Sleeve
Tip to Tip
Sleeve & Ring to Sleeve
Tip to Tip
Sleeve to Sleeve
Hot to Tip
Shield & Cold to Sleeve
Hot to Tip
Shield & Cold to Sleeve
Hot to Tip
Tip (signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Ring (-Signal)
Tip (signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Tip (+Signal)
Sleeve (ground)
