Page 1
OPERATOR'S MANUAL 56-VOLT LITHIUM-ION CORDLESS MOWER Français p. 51 Español p. 103 MODEL NUMBER LM2140SP/LM2140SP-FC WARNING: To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.
Page 3
To reduce your exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
We recommend a Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always use eye protection which is marked to comply with ANSI Z87.1. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
DANGER — Keep Do not mow when children or others Bystanders Away are around. Remove objects that can be thrown by DANGER — Thrown the blade in any direction. Wear safety Debris glasses. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 6
Type or a characteristic of current No Load Speed Rotational speed, at no load Revolutions per Rotational speed minute WARNING: To ensure safety and reliability, all repairs should be performed by a qualified service technician. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Be completely familiar with the controls and proper use of this machine before operating it. Keep this manual in a safe place for future and regular reference and for ordering replacement parts. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 8
Always wear safety glasses or safety goggles during operation and while performing an adjustment or repair to protect your eyes. Thrown objects that ricochet can cause serious injury to the eyes. Always use a face or dust mask if the operation is dusty. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 9
If you feel you are losing your footing, release the motor/blade control handle immediately and the blade will stop rotating within three seconds. ◾ Mow only in daylight or good artificial light. Walk, never run while operating. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
If the slope is greater than 15 degrees, do not mow it. ◾ Mow across the face of slopes; never mow up and down. Exercise extreme caution when changing direction on slopes. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 11
Check the blade and motor mounting bolts at frequent intervals for proper tightness. Also, visually inspect the blade for damage (e.g., bending, cracking and wear.). Replace the blade only with the identical replacement blade, as listed in this manual. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 12
Refer to them frequently and use them to instruct others who may use this tool. If you lend this tool to someone else, also lend these instructions to them to prevent misuse of the product and possibly injury. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
THE MODEL AND SERIAL NUMBERS WILL BE FOUND ON A LABEL ATTACHED ON THE REAR DISCHARGE DOOR. YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE PLACE FOR FUTURE REFERENCE 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Battery 7.5Ah Light load 80 min. 120 min. Medium load 60 min. 90 min. Heavy load 40 min. 60 min. NOTICE: The actual running time will vary with grass condition: species, density, moisture, etc. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
The following part is subjected to be worn out from normal use. Use only identical replacement parts listed below. Use of parts that do not meet the original equipment specifications may lead to improper performance and compromised safety. PART NAME MODEL NUMBER AB2100 Blade AB2101(Compatible) 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
LED Headlights Adjustment Lever Support for Upright Storage Support for Upright Storage Rear Discharge Rear Wheel Front Handle Front Wheel Door Mower Deck Trailing Shield Battery-Release Button Switch Button Power for LED Indicator Headlights 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Quickly stops blade rotation when the bail switch is released. HANDLE-LOCKING CLAMP Locks/unlocks the side rails in the extended or the recessed position. SIDE RAILS Can be extended and locked for operation or recessed for storage. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
LED HEADLIGHTS The LED headlights are located in the front of the mower. This feature provides extra light for increased visibility. SPRING-LOADED CUTTING-HEIGHT ADJUSTMENT LEVER One-handed cutting-height adjustment. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Do not discard the packing material until you have carefully inspected and satisfactorily operated the mower. ◾ If any parts are damaged or missing, please return the mower to the place of purchase. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
3. Assemble the top clips to the frame, as shown in Fig. 3, then assemble the two side clips. Assemble the bottom clip last. 4. The completely assembled grass bag is shown in Fig. 4. Clips 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 21
Position engage in the first position (Fig. 6). Lower This position allows easy access to Operating Locked Storage Position install and remove the grass bag. Position 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 22
The motor cannot be started unless: a) The side rails are fully extended. b) Both green handle-locking clamps are securely closed. c) The handle is locked into one of the three operating positions. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 23
Under normal usage, bag material is subject to wear. To reduce the risk of injury, frequently inspect the bag assembly and replace if there are any signs of wear or deterioration. Use only grass bags manufactured for this mower. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 24
5. Release the discharge door and make sure it rests firmly against the mulching insert. NOTICE: The mulching insert must be removed in order to install and use the grass bag and must be re-installed when the grass bag is removed. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 25
5. To remove the side discharge chute, Step 1 lift the rear-discharge door, grasp the side discharge chute and pull it out. 6. Release the discharge door and make sure that it rests firmly against the discharge chute. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 26
1. Grasp the height adjustment lever, and move it outwards. 2. Move the lever toward the front of the mower and engage the lever in the desired cutting-height position on the mower deck. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
7. Close the battery cover. NOTICE: Make sure that the latch on the mower snaps into place and that the battery pack(s) are secured to the mower before starting operation. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 28
The motor cannot be started unless: ◾ The side rails are fully extended. Bail Switch ◾ (Released position) Both green handle-locking clamps are securely closed. ◾ The handle is locked into one of the three operating positions. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
To stop the mower 1. Fully release the bail switch (Fig. 16). 2. The electric brake in the Automatic Braking Mechanism will stop the blade rotation within 3 seconds of the bail switch release. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 30
Simply push ahead slightly and then move the mower as required. During cutting, at times it may be easier to mow around an object, with the self propel turned off. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 31
15% of its charge capacity. ◾ The red light indicates the battery pack’s charge is low. ◾ The blinking red light indicates that the battery pack is nearly depleted and needs to be charged immediately. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 32
The power indicator on the mower will shine orange and the LED on the battery will flash orange. Release the bail handle, wait until the battery pack cools down to approximately 152°F (67°C), then restart the mower. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
2 1/2’ (0.75 m) every 10’ (3 m)). Mow across the face of a slope and never up and down. Use Fig. 21 as a guide in order to identify slopes that cannot be mowed safety. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. To ensure safety and reliability, all repairs should be performed by a qualified service technician. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
5/16” (8mm) into the fixing hole to act as a stabilizer (Fig. 22). Loosen 4. Use a 9/16 inch (14mm) wrench to turn the blade bolt counterclockwise to loosen it. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Always remove the battery pack when servicing or transporting the mower. NOTICE: To re-install or replace the blade, be sure to replace the parts in the exact order in which they were removed (Fig. 24). 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
A worn or damaged blade can break, causing blade pieces to be thrown from the mower. If the blades are found to be bent, take the lawn mower to an authorized EGO service center for inspection. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 40
It is balanced when neither end drops (Fig. 31). 6. Replace the blade on the mower and tighten it securely (please see INSTALLING THE BLADE). 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
4. Gently pivot the handle toward the front of the mower; release the quick-adjust lever and continue to pivot the handle until you hear and feel the lock pin engage in the locked storage position. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Screw Wave Washer 5. For rear wheel, separate the drive Wheel Axle gear from the worn wheel by loosening and removing the screws. Rear wheel Save them for reassembling the new rear wheel. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 43
Wheel Axle Wheel Cover (Fig. 34). Locking Screw 5. Repeat steps 1 to 3 above the remove the other rear wheel and wheel cover. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 44
6. Store the mower in a covered, enclosed space, that is cool and dry and out of the reach of children. 7. Do not cover the lawn mower with a solid plastic sheet. Plastic coverings trap moisture around the mower, which causes rust and corrosion. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 45
If the mower to tips over from the upright position, mower damage or personal injury may result. Always keep the mower stable and out of the reach of children when it is in the upright position. If possible, lay it flat for storage. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
The cutting height is not set Move the deck height to a higher properly. setting. ◾ ◾ The blade is assembled Reassemble the blade, following incorrectly. the section “INSTALLING THE BLADE” in this manual. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 47
Contact the service center. The motor shaft is bent. ◾ ◾ The handle- The side rails are not fully Fully extend the side rails, then extended. lock the clamps. locking clamps cannot be closed in position 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 48
The claimed load. mower with run time is based on a light load included condition. battery 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
90/30 days from manufacture defects in normal working conditions. d) This warranty is void if the product has been used for rental purpose. e) This warranty does not cover the damage resulting from modification, alteration or unauthorized repair. 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. For customer service contact us toll-free at: 1-855-EGO-5656 or EGOPOWERPLUS. COM. EGO Customer Service, 769 SEWARD AVE NW / Suite 102 Grand Rapids, MI 49504 56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC...
Page 51
GUIDE D’UTILISATION TONDEUSE SANS FIL AU LITHI- UM-ION DE 56 VOLTS NUMÉRO DE MODÈLE LM2140SP/LM2140SP-FC AVERTISSEMENT : Afin de réduire les risques de blessure, l’utilisateur doit lire et comprendre le guide d’utilisation avant d’utiliser ce produit. Conservez le présent guide afin de pouvoir le consulter ultérieurement.
Page 52
Garantie ......... . 101-102 TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Pour réduire votre exposition à ces produits chimiques, travaillez dans une zone bien ventilée et portez l’équipement de sécurité approuvé, comme les masques antipoussière reconnus spécialement pour ne pas laisser passer les particules microscopiques. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Nous recommandons le port d’un masque de sécurité panoramique par-dessus les lunettes ou de lunettes de sécurité standard avec écrans latéraux. Portez toujours un équipement de protection oculaire conforme à la norme ANSI Z87.1. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
à l’écart personnes. Enlevez les objets qui pourraient être DANGER – projetés dans toutes les directions par Projection de débris la lame. Portez des lunettes de sécurité. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 56
Par minute Rotations par minute AVERTISSEMENT : Pour assurer la sécurité et la fiabilité de l’appareil, toutes les réparations doivent être effectuées par un technicien en entretien et en réparation qualifié. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
être formés et supervisés par un parent. Seules les personnes responsables qui connaissent les règles d’utilisation sécuritaire devraient être autorisées à utiliser cet appareil. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
éviter d’évacuer des débris sur la route, le trottoir ou les observateurs. Évitez également d’évacuer des débris sur les murs ou sur d’autres obstacles. Ceux-ci pourraient alors ricocher vers l’utilisateur. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 59
Assurez-vous que vos appuis sont fermes et équilibrés. ◾ Reculez lentement la tondeuse, au maximum à mi-chemin vers vous. ◾ Répétez ces étapes au besoin. ◾ N’utilisez pas la tondeuse sous l’influence d’alcool ou de drogues. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 60
N’utilisez jamais la tondeuse si les dispositifs de sécurité sont endommagés. Cela pourrait entraîner des blessures. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
N’utilisez pas la tondeuse si la pente est inclinée à plus de 15 degrés, comme l’indique l’inclinomètre. ◾ Ne coupez pas l’herbe si elle est mouillée. Un appui instable pourrait vous faire glisser. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 62
Les lames sont tranchantes et peuvent causer des coupures. Recouvrez la lame ou portez des gants et soyez très prudent lorsque vous en faites l’entretien. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 63
à d’autres personnes qui l’utiliseraient.Si vous prêtez cet outil à une personne, prêtez-lui également ces instructions afin de prévenir un usage inapproprié et des blessures potentielles. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
AU CLAPET D’ÉVACUATION ARRIÈRE. NOUS VOUS RECOMMANDONS DE PRENDRE EN NOTE LE NUMÉRO DE SÉRIE ET LA DATE D’ACHAT ET DE LES CONSERVER EN LIEU SÛR AFIN DE POUVOIR LES CONSULTER ULTÉRIEUREMENT. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Forte charge 40 min. 60 min. REMARQUE : La durée de fonctionnement réelle varie en fonction de l’état du gazon, par exemple, de l’espèce, de la densité, de l’humidité, etc. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
L’utilisation de pièces ne correspondant pas aux caractéristiques de l’équipement d’origine peut causer un fonctionnement inadéquat et compromettre la sécurité. NOM DE PIÈCE NUMÉRO DE MODÈLE AB2100 Lames AB2101(compatible) TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Clapet d’évacuation Roue arrière Poignée de Roue avant arrière rangement avant Plateau de coupe Écran postérieur Bouton d’éjection du bloc-pile Interrupteur Indicateur des phares de mise à DEL en marche TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Arrête rapidement la rotation de la lame lorsque l’interrupteur de désengagement est relâché. PINCE DE VERROUILLAGE DE LA POIGNÉE Verrouille et déverrouille les barres latérales en position déployée ou abaissée. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Les phares à DEL sont situés à l’avant de la tondeuse. Ils offrent un éclairage supplémentaire pour améliorer la visibilité. LEVIER À RESSORT POUR RÉGLER LA HAUTEUR DE COUPE Réglage de la hauteur de coupe d’une seule main TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Ne jetez pas le matériel d’emballage avant d’avoir inspecté soigneusement la tondeuse et de l’avoir fait fonctionner de manière satisfaisante. ◾ S’il y a des pièces manquantes ou endommagées, veuillez retourner la tondeuse à l’endroit où vous l’avez achetée. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 71
Figure 3, puis fixez les deux attaches latérales. Fixez ensuite l’attache inférieure. 4. La Figure 4 illustre le sac de déchets de coupe complètement assemblé. Attaches TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 72
(Figure 6). Cette position permet un accès facile pour installer et retirer le sac de déchets de coupe. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 73
TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 74
Pour réduire le risque de blessure, vérifiez fréquemment l’ensemble de sac et remplacez-le s’il présente des signes d’usure ou de détérioration. Utilisez seulement des sacs de déchets de coupe fabriqués pour cette tondeuse. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 75
AVERTISSEMENT : Vous devez enlever le raccord pour déchiquetage avant d’installer et d’utiliser le sac de déchets de coupe, puis vous devez le remettre en place lorsque vous enlevez le sac. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 76
5. Pour enlever la sortie d’évacuation latérale, soulevez le clapet d’évacuation arrière, saisissez la sortie d’évacuation latérale et tirez-la vers l’extérieur. 6. Relâchez le clapet d’évacuation et assurez-vous qu’il repose fermement sur la sortie d’évacuation. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
1. Saisissez le levier de réglage de la hauteur et déplacez-le vers l’extérieur. 2. Déplacez ensuite le levier vers l’avant de la tondeuse et enclenchez-le à la hauteur de coupe souhaitée sur le plateau. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
7. Fermez le couvercle du bloc-pile. AVIS : ASSUREZ-VOUS QUE LE VERROU DE LA TONDEUSE S’ENCLENCHE ET QUE LE BLOC-PILES EST BIEN FIXÉ À LA TONDEUSE AVANT D’UTILISER CELLE-CI. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
◾ les deux pinces vertes de verrouillage de la poignée ne sont pas bien fermées; ◾ La poignée est verrouillée dans l’une des trois positions d’utilisation. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
1. Relâchez l’interrupteur de désengagement (Figure 16). 2. Le frein électrique du mécanisme de freinage automatique arrêtera la rotation de la lame dans les trois secondes suivant le relâchement de l’interrupteur de désengagement. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
à l’aide du levier de réglage de la vitesse du système automoteur. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 82
Phares à DEL sur l’interrupteur pour allumer les phares (Figure 18). Les phares fournissent un éclairage brillant à l’avant de la tondeuse. Appuyez de nouveau sur l’interrupteur pour éteindre les phares. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 83
La lumière rouge indique que la tension du bloc-pile est basse. ◾ La lumière rouge clignotante indique que le bloc-pile est presque déchargé et qu’il est nécessaire de le charger immédiatement. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
DEL de la batterie émet une lumière orange clignotante. Relâchez la poignée de désengagement, attendez que le bloc-pile ait refroidi jusqu’à une température d’environ 67 °C (152 °F), puis redémarrez la tondeuse. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 85
TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
15°, ce qui correspond à un dénivelé d’environ 0,75 m (2,5 pi) tous les 3 m (10 pi). Travaillez parallèlement à la pente, jamais perpendiculairement. Utilisez la figure 21 pour vous aider à déterminer s’il est possible de tondre en toute sécurité sur une pente. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Pour assurer la sécurité et la fiabilité de l’appareil, toutes les réparations doivent être effectuées par un technicien en entretien et en réparation qualifié. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Desserrer 4. Utilisez une clé de 14 mm (9/16 po) pour faire tourner le boulon de la lame dans le sens contraire des aiguilles d’une montre afin de le desserrer. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Pour réinstaller ou remplacer la lame, veillez à replacer les pièces dans l’ordre exact dans lequel vous les avez retirées (Figure 24). 1. Montez le collet intérieur sur le ventilateur (Figure 25). TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 90
(Figure 28). Alignez les deux trous ronds TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
être éjectés de la tondeuse. Si la lame est tordue, apportez la tondeuse à un centre de service EGO autorisé, qui en fera l’inspection. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
équilibrée. Elle est équilibrée lorsqu’aucune des extrémités ne penche vers le bas (Figure 31). TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
4. Faites pivoter la poignée doucement vers l’avant de la tondeuse; relâchez le levier de réglage rapide et continuez à faire pivoter la poignée jusqu’à ce que vous sentiez que l’ergot d’arrêt s’enclenche en position verrouillée pour le remisage et que vous l’entendiez. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
5. Séparez le dispositif d’entraînement et la couronne de la roue usée en desserrant et en retirant les vis. Conservez ces pièces pour remonter la roue arrière. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 95
2. Tournez la tondeuse sur le côté en plaçant le dessus contre un mur. 3. Retirez la roue arrière du côté supérieur en suivant les instructions de la section « REMPLACEMENT DES ROUES » du présent guide. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
à température ambiante. 2. Nettoyez la tondeuse comme il est expliqué à la section précédente. 3. Vérifiez la lame et remplacez-la ou affûtez-la au besoin. 4. Graissez la tondeuse. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
à partir de la position verticale, cela pourrait l’endommager ou causer des blessures. Assurez-vous que la tondeuse est toujours stable et hors de portée des enfants lorsqu’elle est en position verticale. Dans la mesure du possible, remisez-la à plat. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Augmentez la hauteur du inégale réglée correctement. plateau. ◾ ◾ La lame n’est pas fixée Remontez la lame, en correctement. consultant la section INSTALLATION DE LA LAME de ce guide. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 99
Les barres latérales ne sont pas Allongez complètement de fixer les complètement allongées. les barres latérales, puis pinces de verrouillez les pinces. verrouillage de la poignée en place. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 100
La coupe. tondeuse avec durée de fonctionnement indiquée la batterie est basée sur une condition de incluse charge légère. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Ces pièces sont couvertes contre les défauts de fabrication pour une période de 90 jours ou de 30 jours si elles sont utilisées dans des conditions de travail normales. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Pour communiquer avec le service à la clientèle, veuillez composer le numéro sans frais suivant : 1 855 EGO-5656 ou consulter le site Web EGOPOWERPLUS.COM. EGO Customer Service, 769 SEWARD AVE NW / Suite 102 Grand Rapids, MI 49504, États-Unis. TONDEUSE SANS FIL AU LITHIUM-ION DE 56 VOLTS — LM2140SP/LM2140SP-FC...
Page 103
MANUAL DE OPERACIONES CORTADORA INALÁMBRICA DE IONES DE LITIO DE 56 VOLTIOS MODELO NÚMERO LM2140SP/LM2140SP-FC ADVERTENCIA: Para reducir el riesgo de lesiones, el usuario debe leer y comprender el Manual del usuario antes de usar el producto. Guarde estas instrucciones para consultarlas en el futuro.
Page 104
Garantía ......... . 153-155 — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Medidas para reducir la exposición a estos químicos: Trabaje en un área bien ventilada y con el equipo de seguridad aprobado, como las máscaras antipolvo especialmente diseñadas para filtrar partículas microscópicas. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Use siempre protección ocular con la marca de cumplimiento de la norma ANSI Z87.1. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Quite los objetos que puedan ser PELIGRO: Pueden arrojados por la cuchilla en cualquier saltar residuos dirección. Use anteojos de seguridad. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 108
Velocidad sin carga Velocidad de rotación, sin carga ... /min Por minuto Revoluciones por minuto ADVERTENCIA: Para garantizar la seguridad y confiabilidad, todas las reparaciones las debe realizar un técnico calificado. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Solo deben usar esta máquina las personas responsables que conozcan estas reglas para operarla de modo seguro. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Además, evite descargar el material contra paredes u obstáculos que puedan hacer que el material descargado rebote y regrese hacia el usuario. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 111
◾ Repita estos pasos cada vez que sea necesario. ◾ No opere la cortadora bajo la influencia de drogas o alcohol. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 112
Si se presentan situaciones que no están previstas en este manual, tenga cuidado y use el sentido común. Comuníquese con el Servicio al Cliente de EGO para recibir ayuda. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
No pode si el indicador de pendientes indica que la pendiente es superior a los 15 grados. ◾ No pode el césped si está mojado. Un punto de apoyo inestable podría provocar resbalones. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 114
(por ejemplo, dobladuras, rajaduras y desgastes). Reemplace la cuchilla solamente con una cuchilla de repuesto idéntica a la que se indica en este manual. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 115
— CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
PUERTA DE DESCARGA POSTERIOR. DEBE ANOTAR EL NÚMERO DE SERIE Y LA FECHA DE COMPRA, Y CONSERVARLOS EN UN LUGAR SEGURO PARA CONSULTARLOS EN EL FUTURO. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
ESPECIFICACIONES Modelo Número LM2140SP/LM2140SP-FC Sistema autopropulsado Voltaje 56 V Velocidad sin carga 2800 rpm Ajuste de la altura de corte aproximada 1-1/2” (41mm) 2” (51mm) 2-1/2” (65mm) 3” (77mm) 3-1/2” (93mm) 4” (107mm) Tamaño de la plataforma 21” Volumen de la bolsa recolectora 70 L (2,0 boisseau)
NOMBRE DE LA PIEZA NÚMERO DE MODELO AB2100 Cuchilla Compatible con AB2101 — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Rueda frontal posterior almacenamiento Plataforma de la cortadora Protección frontal posterior Botó n para destrabar la batería Botón interruptor Indicador de las luces LED encendido — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 120
Detiene el giro de la cuchilla rápidamente cuando se suelta el interruptor de seguridad. ABRAZADERA DE SUJECIÓN DE LA EMPUÑADURA Traba y destraba los rieles laterales en la posición extendida o retraída. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
PALANCA DE AJUSTE DE ALTURA DE CORTE ACCIONADA POR RESORTES Le permite regular la altura de corte con una mano. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
No deseche el embalaje hasta que no haya inspeccionado cuidadosamente la cortadora y sepa que funciona correctamente. ◾ Si hay alguna pieza dañada o faltante, devuelva la cortadora al lugar donde la compró. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 123
Fig. 3, luego ensamble los dos sujetadores laterales. Finalmente, ensamble el sujetador inferior. 4. En la Fig. 4, se muestra la bolsa recolectora completamente ensamblada. Sujetadores — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 124
(Fig. 6). Esta posición permite un acceso fácil para colocar o quitar la bolsa recolectora. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 125
Asegúrese de trabar ambas abrazaderas verdes de sujeción de la empuñadura. c) La manija está trabada en una de las tres posiciones para operar. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 126
Para reducir el riesgo de lesiones, revise el ensamblaje de la bolsa con frecuencia y reemplácela ante cualquier signo de desgaste o deterioro. Use solamente bolsas recolectoras fabricadas para esta cortadora. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 127
AVISO: Para instalar y usar la bolsa recolectora, debe quitar el accesorio de trituración y volverlo a colocar después de quitar la bolsa recolectora. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 128
5. Para quitar el conducto lateral de descarga, levante la puerta posterior de descarga, tómelo y jálelo hacia afuera. 6. Suelte la puerta de descarga y asegúrese de que quede apoyada firmemente contra el conducto de descarga. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 129
2. Mueva la palanca hacia la parte delantera de la cortadora y enganche la palanca en la posición de altura de corte deseada en la plataforma de la cortadora. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Asegúrese de que las aletas de la cortadora encajen en su lugar y que el paquete de baterías esté bien colocado en la cortadora antes de comenzar a operar. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 131
◾ Asegúrese de trabar ambas abrazaderas verdes de sujeción de la empuñadura. ◾ La manija está trabada en una de las tres posiciones para operar. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 132
2. Después de 3 segundos de haber soltado el interruptor de seguridad, el freno eléctrico del mecanismo de freno automático detendrá la rotación de la cuchilla. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 133
— CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 134
(Fig. 18). Las luces de trabajo brindan una luz brillante en la parte frontal de la cortadora. Para apagar las luces de trabajo, vuelva a presionar el botón interruptor. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 135
La luz roja indica que el paquete de baterías tiene bajo voltaje. ◾ La luz roja parpadeante indica que el paquete de baterías está prácticamente agotado y debe cargarse de inmediato. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 136
El indicador de encendido de la podadora brillará de color naranja y la luz LED de la batería titilará de color naranja. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 137
Use Fig. 21 como guía para identificar las pendientes que no pueden cortarse de modo seguro. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 138
— CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
El uso de otras piezas puede generar un peligro o dañar el producto. Para garantizar la seguridad y confiabilidad, todas las reparaciones las debe realizar un técnico calificado. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 140
4. Use una llave de 9/16 pulg (14 mm) para girar la tuerca de la cuchilla en Desajustar dirección contraria a las manecillas del reloj para desajustarla. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 141
Para reinstalar o para reemplazar la cuchilla, asegúrese de que las piezas estén exactamente en el mismo orden en que las quitó (Fig. 24). 1. Coloque la brida interna en el ventilador (Fig. 25). — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 142
(Fig. 28). Alinear los orificios — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 143
Si las cuchillas están dobladas, lleve la cortadora de césped a un centro de servicio de EGO autorizado para que la revisen. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 144
La cuchilla está equilibrada cuando ninguno de los extremos gira hacia abajo (Fig. 31). — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 145
— CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 146
5. Para la rueda posterior, separe el engranaje del anillo de la rueda desgastada al aflojar y retirar los tornillos. Guárdelos para volver a ensamblar la rueda posterior nueva. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 147
2. Ponga la podadora de lado con la superficie superior contra la pared. 3. Retire la rueda posterior del lado superior según la sección “REPLACING THE WHEELS” (REEMPLAZO DE LAS RUEDAS) de este manual. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 148
4. Lubrique la cortadora. 5. Guarde la cortadora en un lugar limpio y seco. No la guarde junto a materiales corrosivos, como fertilizantes o sal de roca. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 149
Mantenga siempre la cortadora en una posición estable y fuera del alcance de los niños si la guarda en posición vertical. Si fuera posible, guarde la cortadora en posición horizontal. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
La cuchilla no está bien ensamblada. Vuelva a ensamblar la cuchilla siguiendo las instrucciones que figuran en la sección “CÓMO COLOCAR LA CUCHILLA” de este manual. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 151
Los rieles laterales no están Extienda completamente los completamente extendidos. rieles laterales y trabe las de sujeción de abrazaderas. la manija no se pueden cerrar en su posición. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 152
El tiempo de funcionamiento corto de estipulado está basado en funcionamiento condiciones de carga liviana. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
90/30 días por defectos de fabricación en condiciones normales de trabajo. d) Esta garantía queda nula si el producto se ha puesto en alquiler. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Esta garantía le otorga derechos legales específicos, pero podría tener también otros derechos que varían según el estado. — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
Page 155
Para obtener el servicio al cliente, póngase en contacto con nosotros de manera gratuita al: 1-855-EGO-5656 o visite: EGOPOWERPLUS.COM EGO Customer Service, 769 SEWARD AVE NW / Suite 102 Grand Rapids, MI 49504 — CORTA DORA DE CÉSPED INALÁMBRICA DE IONES DE LITIO DE 56 VOLTI OS LM2140SP...
