Heating Specifications
Fuel Burn Rate* (lowest setting) 1.0 lbs./hr. (0.5 kg/hr)
Burn Time (lowest setting)
Hopper Capacity
* Pellet size may effect the actual rate of fuel feed and burn times. Fuel feed rates may vary by as much as 20%.
Use PFI listed fuel for best results.
Dimensions
Height
34" (864 mm)
Width
26" (660 mm)
Depth
27" (686 mm)
Weight
210 lbs. (95.5kg)
VISIBLE SMOKE
The amount of visible smoke being produced can be an effective method of determining how efficiently the
combustion process is taking place at the given settings. Visible smoke consist of unburned fuel and moisture
leaving your stove. Learn to adjust the air settings of your specific unit to produce the smallest amount of visible
smoke. Wood that has not been seasoned properly and has a high wood moisture content will produce excess
visible smoke and burn poorly.
FUEL CONSIDERATIONS
Your pellet stove is designed to burn premium hardwood pellets that comply with the Pellet Fuel Institute (PFI)
standards (minimum of 40 lbs density per cubic ft, 1/4" to 5/16" diameter, length no greater than 1.5", not less
than 8,200 BTU/lb, moisture under 8% by weight, ash under 1% by weight, and salt under 300 parts per million).
Pellets that are soft, contain excessive amounts of loose sawdust, have been, or are wet will result in reduced
performance.
Store your pellets in a dry place. DO NOT store the fuel within the installation clearances of the unit or within the
space required for refueling and ash removal. Doing so could result in a house fire.
SAFETY AND EPA COMPLIANCE
Your pellet stove has been approved for installation in the USA and Canada. It may also be installed in a
manufactured or mobile home. It has been safety tested and listed to ASTM E 1509-04, ULC-S627-00, ULC/ORD
C1482-90, and(UM) 84-HUD by INTERTEK Testing Services in Fairview, Oregon USA.
INSTALLATION OPTIONS
Read this entire manual before you install and use your pellet stove. Failure to follow instructions may result
in property damage, bodily injury, or even death (see specific installation details for clearances and other
installation requirements)
Freestanding Unit - supported by pedestal/legs and placed on a non-combustible floor surface in compliance
with clearance requirements for a freestanding stove installation.
Alcove Unit - supported by pedestal/legs and placed on a non-combustible floor surface in compliance with
clearance requirements for an alcove installation.
Your pellet stove may be installed to code in either a conventional or mobile home (see "Special Mobile Home
Requirements" section of this manual). The installation must comply with the Manufactured Home and Safety
Standard (HUD), CFR3280, Part 24.
It is recommended that only an authorized technician install your pellet stove, preferably an NFI certified specialist.
CAUTION: DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK UNLESS
SPECIFICALLY APPROVED FOR SUCH INSTALLATIONS.
IMPROPER INSTALLATION: The manufacturer will not be held responsible for damage caused by the malfunction
of a stove due to improper venting or installation. Call (800) 750-2723 and/or consult a professional installer if
Specifications
120 hrs. (approximate)
120 lbs. (55kg)
Electrical Specifications
Electrical Rating
110-120 volts, 60 HZ, 3.0 Amps
Watts (operational)
175 (approx.)
Watts (igniter running)
425 (approx.)
Installation
you have any questions.
-4-
