LiftMaster CAPXL Guide Rapide

IF YO U DO NOT H AV E A C CE S S T O L I F T MA S TER C L OU D
PLE AS E CA LL L I F T M AS T E R C U S TOME R C A RE AT
80 0 -3 2 3 -2 2 7 6 T O S E T U P A N A C C O UN T.
SETUP
1 . C RE ATE A N EW L IF T MAS T ER CL OU D FACIL IT Y
1. On the left navigation bar, click Dashboard, then
Facilities tab. Click the Add New Facility button.
2. Enter the Facility information and click Save.
3 . ADD CAP XL TO T HE FACI LIT Y
Open the CAPXL box and locate the CP# on the inside of the enclosure.
1. On the left navigation bar, select Facilities, then click the Controllers tab.
2. Click the Add New Controller button and enter the CP# and name the CAPXL.
5 . C ON FIG UR E DOOR SE TT IN GS
1. Click the Doors tab to edit Door settings including hold open schedule, relay hold
durations, DTMF tone, and Door name.
2. Click the Add Door button to add additional doors (max 4 per CAPXL).
C A P X L
Q U I C K S T A R T
G U I D E
2 . S EL E CT A SUBS CRI PT IO N PL A N
1. On the left navigation bar, click Billing, then select a subscription plan.
2. Enter payment information. If adding the guest management or elevator
integration add-ons, select them during this step.
4 . C O NFI GU R E CAPX L SE T T IN GS
1. Enter CAPXL settings such as the welcome message, custom background image,
and register or link with Phone.com for VoIP calling service.
2. Click Save.
6 . A D D C R ED E NT I AL S
1. On the left navigation bar, click Credentials.
2. Click the Add Credential button to add transmitters, cards, etc. individually or in
bulk to the Facility.
NOTE: A credential must be associated to a person for it to be active. See Step 8.
