INSTALLATION Continued

For Units Used From October 2001

From serial # IN16.0045.1001
The remote rotary control is mounted on a plate measuring
4.72" (120mm) high x 4.72" (120mm) wide that is mounted to
the front of a fabricated cabinet (supplied by others) with 4
screws. The Cut-out opening for the control is 3.40" (86mm)
high x 3.40" (86mm) wide.
Page 12
4.09"
[104mm]
REMOTE
4.09"
[104mm]
4.72"
[120mm]
3.66"
[93mm]
4.72"
[120mm]
Part # 4520895 (01/31/08)
