English
○ Lithium-ion batteries that exceed a power output
of 100 Wh are considered to be in the freight
classifi cation of Dangerous Goods and will require
special application procedures.
○ For transportation abroad, you must comply with
international law and the rules and regulations of the
destination country.
Power Output
Wh
2 to 3 digit number
NAMES OF PARTS (Fig. 1 – Fig. 14)
LED light
Name plate
Motor
Housing
Dust Case
Battery
Strap
Switch panel
Indicator Lamp
Extension Pipe
Crevice Nozzle
Flooring Nozzle
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
R18DB: Cordless Cleaner
To reduce the risk of injury, user must read
instruction manual.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive
2012/19/EU on waste electrical and electronic
equipment and its implementation in
accordance with national law, electric tools
that have reached the end of their life must
be collected separately and returned to an
environmentally compatible recycling facility.
Warning
Nozzle Holder
Intake port
Latch
Protruding mark
Filter
Filter holder
Projection
Housing grooves
Dust
Dust Removal Blades
(3 pcs)
(Fixed to the inside of
the dust case)
Fan fi lter
Switching ON
Switching OFF
Disconnect the battery
Prohibited action
HIGH mode
MID/LOW mode
OFF button
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains
the accessories listed on page 129.
Standard accessories are subject to change without
notice.

SELECTING ACCESSORIES

The accessories of this machine are listed on page 130.
Selecting accessories are subject to change without notice.

APPLICATIONS

○ Light-duty vacuuming of dry surfaces
SPECIFICATIONS
Power tool
Model
Item
Rated voltage
Motor
Application
Continuous
3 (HIGH)
operating time
2 (MID)
(Battery: using
BSL1850/
1 (LOW)
BSL36A18)
Suction Work Rate
Dust collecting capacity
Dimensions (W × D × H)
Weight*
* According to EPTA-Procedure 01/2014
The weight does not include accessories.
8
R18DB
18 V
DC motor
Dry type
Approx. 40 min.
Approx. 48 min.
Approx. 66 min.
3 (HIGH) : Approx. 40 W
2 (MID) : Approx. 30 W
1 (LOW) : Approx. 16 W
560 mL
476 mm × 112 mm × 169 mm
1.7 kg (BSL1850/BSL36A18)
2.0 kg (BSL36B18)
