SURFACE MAINTENANCE:

Do not use corrosive detergents, abrasive detergents or oven cleaners.
Do not use any product containing chlorine bleach or any product containing chloride.
Do not use steel wool or abrasive scrubbing pads which will scratch and damage surface.
Cleaning Stainless Steel
Clean periodically with warm soapy water and clean cotton cloth or micro fiber cloth. Always rub in the
direction of the stainless steel grain. To remove heavier grease build up use a liquid degreaser detergent.
After cleaning use a non-abrasive stainless steel polish/cleaners, to polish and buff out the stainless luster
and grain. Always scrub lightly, with clean cotton cloth or micro fiber cloth and buff in the direction of the
stainless steel grain.
Hybrid Baffle Filters
The hybrid baffle filters installed by the factory are intended to filter out residue and grease from cooking.
They need not be replaced on a regular basis but are required to be kept clean.
Remove and clean by hand or in dishwasher using a non-phosphate detergent. Discoloration of the filter
may occur if using phosphate detergents, or as a result of local water conditions - but this will not affect
filter performance. This discoloration is not covered by the warranty. Spray degreasing detergent and leave
to soak if heavily soiled.
Dry filters and re-install before using hood.
Removing Baffle Filters
1. Push in on spring loaded handle
2. Pull down on filter hande to remove filter

LIST OF PARTS AND ACCESSORIES

DESCRIPTION
Replacement Parts
Baffle Filter (each)
Optional Accessories
Recirculating Kit
Replacement Charcoal Filter (each)
Duct Cover Extension Kit
Universal Make-Up Air Damper
To order parts, visit us online at http://store.zephyronline.com or call us at 1.888.880.8368
PART#
50200050
ZRC-00SI
Z0F-C091
Z1C-00SI
MUA008A
15
