Harmony Defender Reha – CAN Version – 2-in-1 CarSeat – Accessories
Footrest, short, depth 12cm/ 4.7 in (accessory)
Footrest, long, depth 18 cm/ 7.1 in (accessory)
NOTE: You need to use a footrest adapter 821/2 to install a footrest 805/ 806.
Push the footrest tubes into the front of the adapter (Fig. 12a). To do this, depress the
catch springs on the footrest. Always secure the footrest against falling out using the
knurled nut on the left tube of the footrest adapter (Fig. 12b). Multiple holes in the
footrest tubes allow the footrest to be adjusted to match the depth of the vehicle's
seat.
To stabilize the footrest on the vehicle floor adjust the height of the support bars
by screwing them in or out until they have contact with the vehicle. Then lock the
support bars with the hand knobs to prevent them unscrewing accidentally (Fig. 12c).
Screw the hand knobs upwards as far as possible and tighten them fast.
Lower leg length (28 - 43 cm / 11 - 17 in):
The lower leg length is adjusted by changing the height of the footrest. Loosen both
outer screws. Retighten them after each adjustment.
NOTE: You can use a footrest pad (item 834, height 10 cm/ 4 in) if a shorter lower
leg length is required. (Fig. 12d)
Foot angle (Flexion 0 - 10°):
Loosen the four screws left and right on the underside of the footrest to adjust the
desired foot angle with the rails. Then retighten the screws.
NOTE: Footrest and seat wedge below cannot be used in combination.
Seat wedge, below (accessory)
Center the seat wedge (+10° recline) below the Defender Reha seat. (Fig. 5a) The
high edge is at the front to achieve an optimum rest position of the child. (Fig. 5b)
The cover is removable (zipper) and can be maschine washed at up to 30 °C / 86 °F.
NOTE: Footrest and seat wedge below cannot be used in combination.
18
item code: 806
item code: 805
item code: 810
