EN
MEASUREMENT OF INCLINATION
The two arrows in the display indicate in which direction the
instrument has to be moved in order to reach the 0° or 90°
position.
The exact 0° or 90° position is shown by double arrows.
The display has an automatic digit inversion for over-
head measurements.
ADDITIONAL FUNCTIONS
Automatic shut-off
If no button is used for 20 min. the instrument will power off automatically.
Sound
Switch the sound function on. The instrument will now show by a sound signal if the horizontal or
vertical position approaches. The closer the position is the denser the sound signal will be.
If the instrument is in correct vertical or horizontal position the sound will be continuous.
Mode functions [1) - 5)]
1) Slope indication in ° (14,5°)
2) Slope indicaton in % (25,9 %)
3) Indication IN/FT (3 1/8 IN/FT)
4) Indication IN/FT (3,10 IN/FT)
5) Indication mm/m (258,9 mm/m)
Keep the mode button pressed to have all mode functions switch fast. The display will not show any
values. Release the mode button to return to the standard indication.
CONNECTION TO CAMERA TRIPOD
With 1/4"-thread (at the bottom side) S-Digit 60WL + / S-Digit 120WL + can be connected to a camera
tripod.
14
