Changing the Pen Battery

D
•
O NOT REMOVE THE TIP OF THE PEN TO REPLACE THE BATTERY
REMOVE ONLY THE CAP ON THE TOP OF THE PEN
T
•
HERE IS A RISK OF EXPLOSION IF THE BATTERY IS REPLACED BY AN
INCORRECT TYPE
LOCAL INSTRUCTIONS
The pen contains a AAAA-battery. Before proceeding, be sure
to have a new battery available.
Remove the rear Pen Cap (Figure 13).
1
Remove the battery from the pen barrel.
2
Insert the new battery into the pen barrel in the same
3
orientation as the one that was removed.
Close the rear Pen Cap.
4
. D
ISPOSE OF USED BATTERIES IN ACCORDANCE WITH
.
31 - Active Digitizer/Touchscreen
;
.
Pen Cap
AAAA-battery
Pen Barrel
Figure 13. Replacing the Battery
