DTM65-D Product HANDBOOK
Input Parameters:
Description
Nominal input voltage
Input voltage range
Nominal Input frequency
Maximum input current
Input Connections:
Class I AC inlet (3 pin) IEC320-C14 (accepts IEC320-C13)
Output Parameters:
Output channel Vout (V)
DTM65PW050
DTM65PW120
DTM65PW150
DTM65PW180
DTM65PW240
DTM65PW280
DTM65PW360
DTM65PW480
Kycon KPPx-4P or equivalent.
Pin Function
1 -Vout
2 -Vout
3 +Vout
4 +Vout
The DC output cable: 8C+1, UL2464, 16AWG, VW-1, 80°C, 300V
Safety Approvals:
IEC/EN60601-1 3 rd Edition
CSA-C22.2 No.60601-1 Edition 3, ANSI/AAMI ES60601-1
EMC Performance:
Tested to EN60601-1-2 4th Edition. Final compliance must be checked in the end system.
CE mark.
CE marking when applied to any DTM65-PW-xxx product, indicates compliance with the Low Voltage
Directive (2006/95/EC) in that it complies with EN60950-1, 2
(2004/108/EC) and compliance with RoHS Directive (2011/65/EU)
Operation
100-240VAC
90-264VAC
50-60Hz
2A@90VAC
Output Maximum
current (A) power (W)
5 8.0
12 5.0
15 4.0
18 3.6
24 2.7
28 2.32
36 1.8
48 1.35
