Rinse Aid Dispenser - Whirlpool Roper RUD6000 Guide D'utilisation Et D'entretien

Where to fill
Top of 3rd step (9 tsp or 45 mL)
Top of 2nd step (6 tsp or 30 mL)
Top of 1st step (3 tsp or 15 mL)
Soft to Medium Water (0-6 grains per U.S. gallon)
[typical water softener water and some city water]
Soil Level Main Wash
Lightly soiled/Pre- 3 tsp (15 mL)
rinsed dish loads [top of 1st step]
Normally soiled 6 tsp (30 mL)
dish loads [top of 2nd step]
Heavily soiled 9 tsp (45 mL)
dish loads [top of 3rd step]
Medium to Hard Water (7-12 grains per U.S. gallon)
[well water and some city water]
Soil Level Main Wash
All soil types 9 tsp (45 mL)
[top of 3rd step]
NOTE: Fill amounts shown are for standard powdered detergent.
Amounts may vary if you use liquid or concentrated powdered
detergent. Tablet detergents should be placed in the main wash
section of the detergent dispenser with the cover closed. Follow
instructions on the package when using liquid dishwasher
detergent, concentrated powdered detergent or tablet detergent.
IMPORTANT: See "Cycle Selection Charts" for which detergent
dispenser sections to use with each cycle.
Rinse aids prevent water from forming droplets that can dry as
spots or streaks. They also improve drying by allowing water to
drain off of the dishes during the final rinse by releasing a small
amount of the rinse aid into the rinse water. Your dishwasher is
designed to use a liquid rinse aid. Do not use a solid or bar-type
rinse aid.
Checking the dispenser
Check the center of the fill indicator cap. Clear means it needs
filling.
Or you can remove the fill indicator cap. If an "E" is visible, the
dispenser is empty.
Pre-Wash
Filling the dispenser
3 tsp (15 mL)
[top of 1st step]
The rinse aid dispenser holds 6 oz (175 mL) of rinse aid. Under
normal conditions, this will last for about 3 months. You do not
6 tsp (30 mL)
have to wait until the dispenser is empty to refill it. Try to keep it
[top of 2nd step]
full, but be sure not to overfill it.
1. Make sure the dishwasher door is completely open.
6 tsp (30 mL)
[top of 2nd step]
2. Remove the fill indicator cap.
3. Add rinse aid. Fill to the smallest opening in the lower part of
the dispenser. Overfilling can cause the rinse aid to leak out,
and could cause oversudsing.
Pre-Wash
6 tsp (30 mL)
[top of 2nd step]
4. Clean up any spilled rinse aid with a damp cloth.
5. Replace the fill indicator cap. Close tightly.

Rinse Aid Dispenser

OR
9
