5 Install the coupling brackets.
Position the two racks side by side.
a
Adjust the leveling feet on both racks so that the racks are parallel
b
and in the same horizontal plane. For more information, see
"Adjusting the Leveling Feet" on page 30.
Hook the brackets into the square holes inside and adjacent to the rack
c
posts and tighten the brackets using the wing nuts. See Figure 26.
6 Install the front stabilizer feet. See "Installing the Front Stabilizer Feet" on
page 31.
7 Replace the doors and the outer side panels for both racks. See "Removing
the Front Door" on page 10, "Removing the Back Doors" on page 11, and
"Removing and Replacing the Side Panels" on page 13.
Figure 26. Coupling Two Racks
3
2
1 coupling bracket locations
3 coupling bracket (4)
2 wing nut
