HOW TO ATTACH THE SEAT TO THE FRAME
LOCKING LEVER
LOCK
THE SEAT IS NOT REVERSIBLE WITH THE OUTDOOR 3-WHEEL 901 BASE
VIEW
SAFETY RED
FROM BEHIND
PUSH-BUTTON
UNLOCK
AFTER APPLYING BRAKES, PLACE THE
SEAT ON THE MOUNTING PLATE (Fig.
A)
VIEW FROM ABOVE THE FRAME
PUSH THE SEAT BACKWARDS SLIDING
IT ON TO THE MOUNTING PLATE
OPERATE THE LOCKING LEVER. (AS IN
FIG. B) THE CLICK OF THE SAFETY RED
PUSH-BUTTON MEANS THAT IS WELL
LOCKED
FIG. B
43/92
FIG. A
MOUNTING
PLATE
MAKE SURE THE SEAT IS
IN THE MOUNTING PLATE
BEFORE LOCKING IT WITH
THE LEVER
