Madison MELODY-PLUS Manuel D'utilisation page 5

that in some places DAB+ reception is not yet possible.
REP: Press once to repeat current song on the USB/CD input source. Press again to repeat all songs on the USB/
CD input.
EQ: Select one of the 3 EQ pre-sets and DSP OFF: Classic, Pop, Rock.
Number buttons: In DISC/USB mode, select the number of the song you want to play. In FM mode, press the mem-
ory number of the desired FM station.
VOL+: Press to increase the volume
VOL-: Press to decrease the volume
: Press to select previous song/previous station
: Press to select next song/next station
: Press to play/pause music from USB/CD/BLUETOOTH input source
In FM mode, press to enter auto search and auto store stations.
RECOMMENDATIONS FOR BATTERIES
This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in accordance
with your local regulations..
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
When the internal batteries are not to be used, remove them to avoid damage caused by battery leakage or corrosion.
ATTENTION:
Danger of explosion if battery is incorrectly placed.Only replace by the same or equivalent type.
WARNING:
Do not swallow the battery. Danger of chemical burns. Keep new and old batteries out of the reach of children.
If the battery compartment doesn't close properly, stop using the product and keep it out of the reach of children.
If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact immediately a
doctor.
Rear panel
1. AUX input jack
2. REC output to connect to another speaker
3. DC input: Plug the supplied DC adaptor into this socket and the other end
into an appropriate mains outlet. The supplied adaptor is only for use with
this product.
4. FM antenna: adjust the direction of the cable to improve the FM reception
quality.
Connection of BIuetooth
Press input selector key on the front panel or on the remote control and select
the Bluetooth input. Turn the Bluetooth function on your equipment on (such as
mobile phone) and search for a Bluetooth device. Select "MELODY-PLUS" in the
list of found devices. Now you can play your music.
Play CD Disk
This product supports CD, MP3 & WAV music formats. Please insert the CD with the label side upside and accept
standard CD disks only
Trouble-Shooting
If the product is not operating properly, make a check of the items in the table below. If the problem persists, a
malfunction may be assumed. Disconnect the power immediately and contact the store where the unit was pur-
chased.
Problem Causes
• Audio input terminal connected improperly.
No sound • Mains plug & AC jack connection is insecure
• Volume control set to minimum.
Distortion •The volume is too loud.
Unit can't be Power plug is not plugged in properly or is damaged Try to plug it in again
turned on
No batteries inserted or exhausted
Remote control
doesn't work
Remote control is used out of the operational range
MELODY-PLUS
© Copyright LOTRONIC 2020
Corrections
• Check the audio terminal.
• Connect the power properly.
•Tum volume up to a suitable level.
• Reduce volume.
Replace batteries
Use in within the operational range
5
