Product overview

1 Insertion slot for battery
2 Switch interlock
3 Fastening loop
4
Handlebar
5
Locking button (operating mode)
6 Shaft coupling
7 Locking button (operating angle)
8 Running wheel
9 Lock button (cutting head)
10 Cutting head
11 Safety guard
12 Motor housing
13 Lower shaft
14 Upper shaft
15 Locking lever (handle bar)
16 On/Off switch
17 Handle
Assembling the trimmer
1
Remove the 4 screws around
the cutting head 10. Fix the
safety guard 11 with the screws
and tighten them.
3
Insert the plant guard 2 into the
respective holes (1). Fold up-
wards if not needed (2).
EN
102

Intended Use

This garden tool is intended for trim-
ming and cutting lawn edges and
small grassy areas and lawns accord-
ing to the descriptions and safety in-
structions indicated in this operating
manual. It is not suitable for trimming
bushes, hedges and shrubs. The tool
is not intended for commercial use.
Any use not compliant to the descrip-
tion in this manual or any modifi-
cation to the tool is considered as
improper use and could cause con-
siderable dangers. The manufacturer
is not liable for any type of damage
resulting from this: the user bears the
sole risk.
2
Insert the running wheel 8 into
the holder until it clicks into
place. To dismantle, use a tool
to lift the retaining tab.
4
Hook the shoulder belt into the
fastening loop 3 (1.) and adjust
the belt to your height (2.).
Warning! Before performing
any work on the tool, remove
the battery.
